Latest pile driver with engine! Reliable small/mini crawler hydraulic rotary drilling rig KR125A
- 1000 Set / Sets per Month
- Qingdao port or others
- T/T Credit Card PayPal
You May Like
-
Factory price auger pile driver/drilling rig
-
Highway Guard rail Hydraulic Pile driver dig for 3meter depth/construction machine/dig fundation machine
-
Crawler Rotary Diesel Engine Drill Rig / Pile Driver From China
-
drill depth 6-14m diameter 150-800mm bore pile driver/piling machine
-
Excavator mounted hydraulic sheet pile driver vibro hammer for concrete piles
-
Factory price Long Auger Drill Machine/pile driver press machine
Product Details
Condition | New | Efficiency | 2000mm/min | |
Piling Speed(m/min) | 22/40 | Place of Origin | Shandong, China | |
Brand Name | QK | Model Number | YD-70 | |
Weight | 200Kg | Dimension(L*W*H) | 860*225*310 | |
Certification | ISO9001:2008 | After-sales Service Provided | No overseas service provided |
Product Description
Latest pile driver with engine! Reliable small/mini crawler hydraulic rotary drilling rig KR125A
Spiral hammers Features
1. Full Hydraulic controlling system.
2. Hydraulic stabilizer legs.
3. People can drive to move like a car, as you can see in the picture.
4. Easy operation, people without experience can handle it in short time.
5. Reasonable structure, flexible transport, remote control.
6. Max. 15m, 600mm~1000mm diameter.
products discription
Production of various types of small screw driver, pile diameter 15 cm to 1 m, piling depth
6 meters - 14 meters, walking four cylinder type 4102 single cylinder engine with L32 / flashes,
bit of 15 kw power - 30 kilowatts, hoist lifting heavy 1 ton to 3 tons, with 30 kw generator set to
50 kw, rotated 360 degrees, convenient operation, and is equipped with hydraulic direction.This
car can power generation and its external power supply dual-use, applicable to the construction industry, highways, electric power facilities,such as piling.This car has quick
positioning, pile drawing quickly, high efficiency, etc.
parameters
type | YD-70 |
Size(mm) | 860*225*310 |
Shaft distance(mm) | 2800 |
Wheel distance(mm) | 1300 |
Drill rod diameter(mm) | 150-800 |
depth(m) | 6-14 |
Motor power(kw) | 40(50) |
Lifting ability/power(T/kw) | 2(3)/7.5(11) |
Power head (kw)/speed(rpm) | 22/40 |
Rotating motor power(kw) | 1.5 |
Engine type/power(kw) | Weicai 4102(47) |
Tire size | 750-16 |
Direction | hydraulic |
operation | In the fix position dual track around back and forth motion and rotation can spontaneously electricity and power converter (380v) |
Rotation angle | 300 |
Walking speed(kw) | 50 |
Packaging: wooden case or as client requires
Shipping: within 5 days after received the deposit.
1.Supply item design,process design.
2.Help you to chose the fit machine.
3.Making the machine according to your requirement.
Sale Service
1.Acceptance equipment together with you.
2.Help you to make the method statement and the details of the process.
After Service
1.Guarantee for a year.
2.Quality problem,we will send you the accessories.
3.Free repair whole using life(without the freight and accessories charge).
Jining Qingke Machinery Co.,Ltdestablished in July 29, 2015, registered capital of 5 million . this is our new branch. Our factory has 6 years history. We have CNC machining center, CNC lathe,boring machine,and milling machine.
Main products: steel bar cutting machines, bending machines,straightening and cutting machines, electric vibration impact machines, ground polishing machines, terrazzo machines, adjustment electric hoisting machines.Solar water pump.Garden Machinery including tree spade , lawn mower, Construction machinery and accessories, Road Marking and Mining equipment, Mining tools and so on.
we passed the ISO9001:2000 certification. Our company products have been exported to Europe, Russia, south America, Africa,more than 20 countries.
