Italy quality Kroea technical Iroller leather ironing machine

Specifications

roller leather ironing machine
1.roller embossing machine
2.1800 to 3200mm
3.ironing and embossing
4.three roller press

Model	DCH	1600	2100	3000	3200
Working width	Mm	1600	2100	3000	3200
Working pressure	Kg/cm	240	240	200	240
Power(3 roller)	Kw	87	102	120	135
Power(1 roller)	kw	25	30	35	40
Working temperature	Degree	180	180	280	180
Working speed	m/min	3/17	3/17	3/17	3/17
Weight (auto)	Kg	14000	15500	17300	18800
Weight (crane)	kg	11900	10900	12300	12600
Weight of one roller	Kg	1100	1300	2000	2100
Overall dimensions	mm	4100x2200x2400	4600x2200x2400	5500x2200x2400	5700x2200x2400

1.super solid frame. No deformation: using he special steel which has taken the heat treatment and stress treatment ,this machine can keep its sharp under the high pressure

2.using super heavy roller to ensure the embossing effect: the diameter of pressure roller is 500mm ,and the diameter of pressure roller is 700mm , we also using special material to ensure the quality of embossing work

3.automatic roller change device: on one shaft, 3 roller are installed (two for embossing ,one for iron),by using the reducer ,rollers can be shifted automatically ,this techniology is unique in the china

4.multiple rollers independent heating system ,each roller has its own heating system , by pushing the bottom ,the working roller can be shifted to the work position to heat , no extra heating is required

6.the heat uniformity or distribution systems by computer control: the system of heat oil inside, control by computer distribution technology keep the temperature of roll face uniformity

7.special techniques,ressure regulating device:10 pressure ironed up to 150kg pressure of the ironing ,the most important is the pressure from 10 to 150 kg pressure process can he fine –tuning ,this technology is the first in the country

8.the device of unique leather stretch contribute :even a think sheep leather ensure the stretching process does to fold ,improve the leather rate

9.automatic hydraulic felt adjusting system ,ensure felt in central position
