Home > Products > Lathe > Mini Lathe

Mini Lathe

FOB Price

Negotiable / Set

10 Sets(Min.Order)

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Condition:	New	Type:	Other, Mini lathe	CNC or Not:	Normal
Automatic Grade:	Semi-Automatic	Max. Swing Diameter:	180mm	Place of Origin:	Shandong, China
Brand Name:	Eagle	Model Number:	ML180	Voltage:	220V
Power(W):	350W	Dimension(LWH):	870340380mm	Weight:	44/50kg
After-sales Service Provided:	No overseas service provided

aa Constructed with cast iron giving great rigidity
aa Precision ground Vee bed slide ways
aa Fully featured saddle and carria

Mini Lathe

Specifications

Swing over bed	180mm
Distance between centers	350mm
Hole through spindle	20mm
Spindle taper	MT3
Tailstock taper	MT2
Cross slide travel	65mm
Compound travel	55mm
Range of thread Metric version	0.4-2.0mm(10 thread pitche)
Imperial version	12-52TPI(18 thread pitche)
Motor output power	350W
Spindle speed(variable speed) Low range	100-1200±10% rpm
High range	100-3000±10% rpm
Overall dimension(L×W×H)	800×300×300mm
Packing size(L×W×H)	870×340×380mm
Weight(Net/Gross)	44/50kg
Model	ML180/350
Item Number	100110

Standard attachment

80mm 3-jaw Chuck

MT2 Center

Changing gear set

Wrench set

Oil can

OPTIONAL ACCESSORIES

S/N:10005	Cutter 11 pieces set
	DIN 4971R Straight cutter
	DIN 4972R Angle cutter
	DIN 4973R Bore cutter
	DIN 4974R Bore cutter
	DIN 4975 Tip cutter
	DIN 4976 Wide edge cutter
	DIN 4977R Right external turning cutter
	DIN 4978R External turning cutter
	DIN 4980L Left angle cutter
	DIN 4980R Right angle cutter
	DIN 4981R Cutter
S/N:10008	Steady rest
S/N:10009	Follow rest
S/N:10007	Face plate 160mm
S/N:10007	Bolt size 12mm
S/N:10007A	Clamping kit for face plate
S/N:10007A	Bolt size 8mm
S/N:10200	Cutting set 8mm(Tin Coated)
	DIN 4977R Right external turning cutter
	DIN 4980L left cutter
	DIN 4980R Right cutter
	DIN 4975R Thread cutter
	DIN 4981R Cutter
S/N:10200-1	Tip replacement set
S/N:10140	DRCD kit
S/N:10031	Workshop practice series book"The Mini-Lathe"
S/N:10100	100mm 3-jaw chuck
S/N:10100A	100mm 3-jaw chuck whe flange
S/N:10010	80mm 4-jaw chuck
S/N:10029A	100mm 4-jaw chuck with flange
S/N:10013	Spindle center MT#3
S/N:10014	Rolling center MT#2
S/N:10015	Lathe dog
S/N:10147	Rolling tailstock chuck
S/N:10147	Dia.13mm+MT#2
S/N:10148	Mill chuck set(metric)
S/N:10148	chuck dia. 4,6,8,10,12,14,16mm
