high efficiency China double chamber baler

FOB Price

USD $5,000 - $5,000 / Set

2 Sets(Min.Order)

Supply Ability 100 Set / Sets per Month
Port qingdao/Tianjin

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Type:	Other	Operating Speed:	2-5km/h	Condition:	New
Place of Origin:	Henan, China	Brand Name:	kefan	Model Number:	kf70
Application:	Hay	Dimension(LWH):	332028802800	Weight:	2000 kg
Certification:	CE ISO	Warranty:	One Year	After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

high efficiency China double chamber baler

[Production capacity]: 150 acres / day
[Advantages]: using floating spring suspension frame, picking up device height through screw pole can make stepless adjustment.

[Applications]: Suit to process corn straw, medicago chih alfalfa, sugarcane caudate lobe, sweet potato vine, reed and bean seedlings' silage, making crop waste turning waste into treasure.

Product Details

Square bundles pick up baler all called baler, as after pressed output bundles belong to square shape, adopt pick up feeding method, thus, called square bales pick up baler. Main used to field all kinds grass, rice straw, wheat straw and other crops harvest. It can automatic pick up field laying grass, through conveying, feeding, press forming, bundling and other working process.

Property advantages:

1. Picking up device connect with machine frame, using floating spring suspension frame, picking up device height through screw pole can make stepless adjustment.

2. Reasonable feeding mechanism: main consist of left and right crank, shake pole, feeding fork and chain, etc. During the machine working process, under shake pole control, feeding fork working according predetermined trajectory, add accumulate at feeding port material from bundling chamber bottom position feeding to bundling chamber.

3.Safety device: at flywheel front section installed sliding friction clutch to limit piston during pressing process happened overload phenomenon occasionally. When overload, clutch will transient slip to protect the machine free from damage.

4. Square bundles baler with grass bundles density control device itself, can adjust grass bundles density and grass bundles size by hand.

Technical Parameters

Bundling chamber	Transverse cross-sectional area	360x460mm
	Grass bundle length	310~1300mm
	Grass bundle density	120~180kg/m3
Pickup device	Outside width between baffles	2264mm
	Inside width between baffles	1928mm
	Spring tooth pole qty and spring tooth	3 strip, 112 pcs
	Auger diameter	Outside diameter280mm
	Contour wheel	2 pcs(1 pcs per side)
Feeding device	Structure formation	Crank rocker type, 4 pcs feeding forks
Feeding device	Feeding chamble volume	2851cm3
Piston	Working speed(Reciprocate times)	100times/min
Piston	Working formation length	550mm
Bundling mechanism(rope)	Tie a knot device qty	2 pcs
Bundling mechanism(rope)	Bundling box volume	6 bundles
Matched tractor	Power output shaft speed	540r/min
Matched tractor	Power	>horsepower
Baler	Overall dimension(LWH)	3300x2350x1725mm
Baler	Weight	1.7t
