YL51/51C 2 ton Ride-On Hydraulic Double Drums Road Roller

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 1000 Set / Sets per Month
Port Ningbo/Shanghai
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Condition:	New	Type:	Double Drum Roller	Static Linear Pressure:	17KN
Travel Speed:	0~8KM/H	Grade Ability:	30%	Place of Origin:	Zhejiang, China
Model Number:	YL51/51C	Dimension(LWH):	246011401700MM	Weight:	1480KG
Certification:	CE	After-sales Service Provided:	Overseas third-party support available

Product Description

Specifications

1.Famous brand engine
2.Imported hydraulic motor
3.Front drum hydraulic turning,turning angle 15degree
4.Sling position

YL51/51C Ride-on Hydraulic Vibratory roller

The machine is mainly used to compress on the asphalt, sand soil and gravel. It is also used to compress on track in the school and planish the lawn. This is the latest model of light duty rollers in the domestic.

1. Famous brand engine, excellent performance, easy to start-up;

2. Famous brand variable pump, fixed displacement motor, stepless speed, easy to change direction;

3. Hydraulic diversion, efficient and convenient;

4. The whole machine could be controlled by instrument panel;

5. NSK bearing, excellent performance;

6. Comfortable driving seat;

7. Streamline surface, more beautiful;

Type	RWYL51		RWYL51C
Run
Speed	0-8km/h
Turning radius	1900mm
Climbing capacity in theory	30%
Compaction
Static load forward/back	55/66N/cm
Nominal amplitude	0.5mm
Vibration frequency	65Hz
Exciting force	17kN	21kN
Water tank volume	150L
Working
Drive	Variable plunger pump , constant displacement hydraulic motor
Vibration	Gear pump, Gear motor
Turning	Redirector , hydraulic ram
Stop braking	Hand draw and friction
Engine
Model	HONDA, GX630		Perkins 403D-11
Type	Gasoline engine, air cooled,4stroke,OHV,double cylinder		Diesel engine, water-cooled, 4stroke, three cylinder
Power	20hp/3600rpm		25hp/2800rpm
Fuel tank volume	30L
Lubricant L	1.8L		3.8L
Fuel consumption	313g/kWh		281g/kWh
Dimension
Width of steel wheel	900mm
Diameter of steel wheel	560mm
Tread	1340mm		1420mm
Total length	2270mm		2350mm
Total width	980mm
Total height	2250mm
Packing size	2460×1140×1700mm
Weight
Working weight	1480kg		1700kg
