Home > Products > Belt conveyor > 430-850 t/h, long life rubber conveyor belt price
430-850 t/h, long life rubber conveyor belt price
- 500 Meter / Meters per Month
- Dalian Shenzhen Tianjin Shanghai Guangzhou
- T/T L/C Credit Card PayPal
You May Like
Product Details
Condition | New | Type | Gravity Conveyor | |
Material | Rubber | Material Feature | Other, High wear resistance | |
Structure | Belt Conveyor | Place of Origin | Henan, China | |
Brand Name | Hongyun | Model Number | HY-1000 | |
Power(W) | 7500 | Dimension(L*W*H) | According to the requirements of customers | |
Certification | CE, ISO | After-sales Service Provided | Engineers available to service machinery overseas |
430-850 t/h, long life rubber conveyor belt price.
Standard in container, small parts are packed in wooden case. Special packings are provided in accordance with the requirements of customers.
Product Description
430-850 t/h, long life rubber conveyor belt price
It is an ideal high-efficiency continuous conveyor and widely used in coal, transportation, water, electricity, mineral processing, chemical, food, metallurgy and other industries, which is able to improve the production efficiency.
Belt conveyor is also called ribbon conveyor because it is composed of frame, conveyor belt, roller, rattle, tensioning device, transmission device and other parts, and it looks linear.
1 The belt conveyor runs smoothly, thus it can do a large quantity of transmission work;
2 The length can be adjusted according to users’ needs. It also can be used as a series by connecting each other to make up for the disadvantages of production environment. At the same time, it can reduce the use of labor force.
3 Wide application range.
4 More automotive and easily controlled centralized. Besides, it can adjust the transfer speed and the quantity of flow.
5 Because of its simple structure and light rack, it is easy for disassembling and assembling to make the dairy maintenance convenient.
6 There is no leakage of materials when running because of its compact structure and good sealing.
7 Low investment cost. It has strong universality and can be used in many industries.
8 It can be extended and shortened according to the working needs and can adjust the driving equipment to meet the production needs.
Model | Bandwidth (mm) | Layers of framework | Conveying speed (m/s) | Conveying capacity (t/h) | Power (kw) |
HY-500 | 500 | 1 | 1.3-1.6 | 60-150 | 3 |
HY-650 | 650 | 1 | 1.3-1.6 | 130-320 | 3 |
HY-800 | 800 | 1 | 1.3-1.6 | 280-540 | 4 |
HY-800 | 800 | 2 | 1.3-1.6 | 280-540 | 4 |
HY-1000 | 1000 | 2 | 1.3-2.0 | 430-850 | 7.5 |
HY-1200 | 1200 | 2 | 1.3-2.0 | 655-1280 | 11 |
Note: This specification is just reference, any change are subject to the products.
Gongyi Xiaoyi Hongyun machinery factory is a manufacturer which professionally researching and developing sand production line, stone production line, mechanism sand production line, quartz sand production line, mineral processing production line, magnetic separation production line, flotation production line, construction waste processing production line, preparation equipment and other products.
1.One package service including the buyers’ process design, on-site construction guidance, equipment installation and debugging, training technical persons and operators.
2.One year warranty.
3.Long-term supply of components.
our factory
customers visit
Company Profile

Gongyi Xiaoyi Hongyun machinery factory has 20 years of production experience and performance in the mineral processing equipment and baking-free brick equipment industry, which changes from state-owned enterprise to private enterprise. We have been being committed to product the coal gangue crusher, shale crusher, fine crusher and slag crusher, and improve constantly their performance and efficiency. Recently, combined with foreign advanced technology, we developed three-warehouse compound crusher and three-warehouse fine crusher, which both make high efficiency and energy saving as the theme.
Gongyi Xiaoyi Hongyun machinery factory has a modern enterprise management system, first-class equipment, perfect detection means, high-quality scientific research persons, high-quality tracking service, and face customers with highly dedicated spirit. It is constantly rated "advanced quality management enterprise" and "value-contract and keep-credibility enterprise" for many years.
We has been keeping the attitude that only customers are satisfied, can we are satisfied to keep pace with the times. We have many skilled technical persons and experienced after-sales service team, so we can offer customers a full of crushing screening from monomer to solutions. And we can provide customers with professional technology support, reliable supply of spare parts and high quality of after-sales service.
