Full automatic pcl sand making machine with high quality in Nigeria

Name: Full automatic pcl sand making machine with high quality in Nigeria
Brand: Hongyun
Availability: InStock

FOB Price

USD $43,000 - $50,000 / Set

1 Set(Min.Order)

Supply Ability 11 Set / Sets per Month
Port Shanghai Guangzhou Dalian Qingdao
Payment Terms:T/T L/C Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Condition:	New	Production Capacity:	According to the different types	Place of Origin:	Henan, China
Brand Name:	Hongyun	Model Number:	VSI8518	Voltage:	380v
Power(W):	180kw	Dimension(LWH):	414022802425mm	Weight:	14.5t
Certification:	CE ISO	Warranty:	1 year	After-sales Service Provided:	Engineers available to service machinery overseas

Packaging Details

Full automatic pcl sand making machine with high quality in Nigeria uses standard export containers, nude packing for main machine, plywood box for spare parts or the package of the stone sand making machine can be according to customers' requirements.

Product Description

Full automatic pcl sand making machine with high quality in Nigeria

Large output low cost stone production line price from China supplier is the advanced crushing equipment developed by Hongyun Factory based on the present situation about sand making equipments’ application in our country. It is mainly composed of pedestal, holder, vortex crushing cavity, impeller, distributor, main shaft and other parts. Stone sand making machine is the indispensable fine devoice in the present sand production industry. Using the centrifugal force and impact force which are brought by itselves’ high speed running, the sand making machine can achieve crushing effect to satisfy the sand making industry’s demand of materials’ granularity and size. Besides be used in sand making industry, it can also used to crush harder ore material. It is an ideal crushing equipment which often be used in mineral processing, ore milling, metallurgy, chemical engineering, power industry, water resource industry and other different industries.

Advantages:

Widely application. In addition to crushing gravel materials with remarkable effect, it also has good effect on harder ore material.
High comprehensive utilization value. It can be applied in the different industries.
Vortex crushing chamber and the impeller can form self circulatory system of internal airflow to provide a natural ventilation for using the device.
Using the distributor can improve the performance of the equipment, because it can make the conveying of material more continuous, timing and quantitative.
According to the overall usage of stone sand making machine, it can be deployed dry oil pump to provide oil for bearing parts regularly.
With double motor drive, the gearing can run smoothly.
With the wear-resisting plate of special material in the crushing cavity of equipment, it can improve usability and wear resistance of the core crushing area.
Holder has detachability. Users can disassemble or assemble it based on the different workplaces.

Model		VSI7611	VSI8518	VSI9526	VSI1140
Capacity	Cascade and Center Feeding	120-180	200-260	300-380	450-520
Capacity	Center Feeding	60-90	100-130	150-190	225-260
Feeding Size(mm)	Soft Material	35	40	45	50
Feeding Size(mm)	Hard Material	30	35	40	45
Rotation Speed		1700-1890	1520-1690	1360-1510	1180-1310
Power of the Double Motors		110	180	264	400
Overall Dimension		3700×2150×2100	4140×2280×2425	4560×2447×2778	5000×2700×3300
Weight		11.8	14.5	17.8	25.6
Power Supply		380V,50Hz
Vibrating Sensor		Inspection scope:0.1-20mm/s can be adjusted continuously
Lubrication hydraulic station	Power of Double Oil Pump	2×0.25Kw
	Overall dimension	820×520×1270
	Power of Oil-box Heater	2Kw
