New fine sand maker factory/sand making machine

Name: New fine sand maker factory/sand making machine
Brand: Hongyun
Availability: InStock

FOB Price

USD $60,000 - $62,000 / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port Qingdao Shanghai Dalian Tianjing Lianyungang All inland ports
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Condition:	New	Place of Origin:	Henan, China	Brand Name:	Hongyun
Model Number:	VSI9526	Voltage:	380v	Power(W):	264kw
Dimension(LWH):	456024472778 mm	Weight:	17.8t	Certification:	ISO CE
Warranty:	1 Year	After-sales Service Provided:	Engineers available to service machinery overseas

Packaging Details

Large output mining sand making machine has export standard package,also can do package as customers' requirements.

Product Description

Using the centrifugal force and impact force which are brought by itselves’ high speed running,

it can achieve crushing effect to satisfy the sand making industry’s demand of materials’ granularity and size. Besides be used in sand making industry,

it can also be used to crush harder ore material. It is an ideal crushing equipment which often be used in mineral processing, ore milling, metallurgy, chemical engineering, power industry, water resource industry and other different industries.

Advantages

Wide application. In addition to crushing gravel materials with remarkable effect, it also has good effect on harder ore material.
High comprehensive utilization value. It can be applied in the different industries.
Vortex crushing chamber and the impeller can form self circulatory system of internal airflow to provide a natural ventilation for using the device.
Using the distributor can improve the performance of the equipment, because it can make the conveying of material more continuous, timing and quantitative.
According to the overall usage of sand making machine, it can be deployed dry oil pump to provide oil for bearing parts regularly.
With double motor drive, the gearing can run smoothly.
With the wear-resisting plate of special material in the crushing cavity of equipment, it can improve usability and wear resistance of the core crushing area.
Holder has detachability. Users can disassemble or assemble it based on the different workplaces.

Technical parameters

Model		VSI7611	VSI8518	VSI9526	VSI1140
Capacity	Cascade and Center Feeding	120-180	200-260	300-380	450-520
Capacity	Center Feeding	60-90	100-130	150-190	225-260
Feeding Size(mm)	Soft Material	35	40	45	50
Feeding Size(mm)	Hard Material	30	35	40	45
Rotation Speed		1700-1890	1520-1690	1360-1510	1180-1310
Power of the Double Motors		110	180	264	400
Overall Dimension		3700×2150×2100	4140×2280×2425	4560×2447×2778	5000×2700×3300
Weight		11.8	14.5	17.8	25.6
Power Supply		380V,50Hz
Vibrating Sensor		Inspection scope:0.1-20mm/s can be adjusted continuously
Lubrication hydraulic station	Power of Double Oil Pump	2×0.25Kw
	Overall dimension	820×520×1270
	Power of Oil-box Heater	2Kw

2Kw

Packaging & Shipping

Relative product

Hongyun machinery factory professionally specialize in researching and developing all kinds of vibrating feeders, the models are various. Our company owns strong tcehnical power and perfect services. welcome to contact us.

Company Profile

Gongyi Xiaoyi Hongyun Machinery Factory

Gongyi Xiaoyi Hongyun machinery factory has 20 years of production experience and performance in the mineral processing equipment and baking-free brick equipment industry, which changes from state-owned enterprise to private enterprise. We have been being committed to product the coal gangue crusher, shale crusher, fine crusher and slag crusher, and improve constantly their performance and efficiency. Recently, combined with foreign advanced technology, we developed three-warehouse compound crusher and three-warehouse fine crusher, which both make high efficiency and energy saving as the theme.
Gongyi Xiaoyi Hongyun machinery factory has a modern enterprise management system, first-class equipment, perfect detection means, high-quality scientific research persons, high-quality tracking service, and face customers with highly dedicated spirit. It is constantly rated "advanced quality management enterprise" and "value-contract and keep-credibility enterprise" for many years.
We has been keeping the attitude that only customers are satisfied, can we are satisfied to keep pace with the times. We have many skilled technical persons and experienced after-sales service team, so we can offer customers a full of crushing screening from monomer to solutions. And we can provide customers with professional technology support, reliable supply of spare parts and high quality of after-sales service.
