Specifications
1, Multifunction2, asselbled screw
3, 4 temperature mesure points
4, 3 pressure measue points
5, speed controled
Laboratory(lab) experiment twin screw extruder
Lab twin-screw extruder is our company research for universities, research institutes and large and medium-sized enterprises engaged in various extrusion, extruded maturation, extruded variability study omnipotent models.
It has gone through four generations of improvements to adapt to cereals, potato starch, protein, chemicals, plastics, rubber and other raw materials are vastly different for a variety of experiments. Powerful, easy to operate and simplely of parameters adjustment, test data accurate, easy maintenance .
1, The screws are made by ally steel and special craft, the screw life is longer, uses building block system structure, may combine willfully.
2, The forced lubrication system, by guaranteed equipment transmission longer life.
3, Visible auto-temperature controlling system, make the temperature-controlling to be more direct-viewing, parameter to be more precise.
4, Screw speed and wide temperature range :screw speed arbitrary adjustments between 0 and 500 RPM. temperature arbitrary regulation at room temperature to 300 degrees.
Engine power | 5.5KW | Second series L/D | 9.3 15 20.6 | Pressure scope | 0-30MPa |
Engine speed-control | Frequency speed-control | Heating way | Heating ring | Pressure precision | 0.1MPa |
Screw diameter | 30 | Cooling way | Water | Number of measuring pressure | 3 |
Screw central distance | 26mm | Temperature scope | 20°C-300°C | Model cooling way | Water |
Speed range | 0-500rpm | Temperature precision | ±1.0°C | Filling intake | 3 |
Screw mode | Building block-combined type | Number of measuring temperature point | 4 | Water intake | 3 |
First series L/D | 11.6 12.7 23 | Output | 10-25KG/H | Percent of water | 6%-7% |
4. Service
4.1 The warranty period is one year.
4.2 Our service is turn-key mode, which includes installment, debugging and train.
4.3 Supply quick-wear part and general tool.
4.4 Supply the basic formula of raw materials.
The most important thing is that,we have 3 wonderful engieners, who have more than 20 years' experience, and
ready for the after-sale installation service.
5. Honors
6. Packing and delivery
7. About us:
User Experience
Perfect user experience is our brief.
We hope every person who is our client can be our friend. We know, it is based on high quality of products and warm & thoughtful service. We have done, be doing and will do our best to meet every client's requirement. You can find the smiling faces of both our clients and ours---all of us are so happy.
Due to our cooperation ,we have helped our client got big profit!
Click on us, you will be the next succeed one!
