PE 900*1200 jaw crusher best selling

Specifications

PE 900*1200 jaw crusher best selling
1.samples design within 24 hours
2.exported to 20 countries
3.quality is prior

                               PE 900*1200 jaw crusher best selling


Our company established in the 1970s , Henan Yuhui Mining Machinery Co., Ltd has developed into a manufacturer

specialized in producing mineral dressing equipment , sand making equipment, cement  equipment, compound fertilizer

equipment .



1. Features of jaw crusher:



A crusher is a machine designed to reduce large rocks into smaller rocks, gravel, or rock dust. Crushers may be used to reduce the size, or change the form, of waste materials so they can be more easily disposed of or recycled, or to reduce the size of a solid mix of raw materials (as in rock ore), so that pieces of different composition can be differentiated.



2.Working principle:

The motor transmits power through belt, drives the moving jaw do periodic motion to the fixed jaw surround the eccentric shaft. The angle between toggle plate and moving jaw increases when moving jaw moves up. So the moving jaw closes to the fixed jaw. The stuff will be crushed in this process. The angle of Jaw Crusher between toggle plate and moving jaw decreases when moving jaw moves down, the moving jaw of Jaw Crusher moves away from fixed jaw by the pulling of rod and spring, the products after crushing will be discharged from the outlet of Jaw Crusher.



3.Main technical parameters:

Model	Feeder Opening (mm)	Setting Adjustment Range(mm)	Max. Feeding Size (mm)	Capacity (t/h)	Motor Power (KW)	Weight (t)
PE150×250	150×250	10-40	125	1-3	5.5	1.5
PE250×400	400×250	20-50	200	5-25	15	2.4
PE400×600	600×400	40-100	350	15-60	30-37	7
PE500×750	500×750	50-100	425	40-110	45-55	12
PE600×900	900×600	65-160	480	90-180	55-75	17
PE750×1060	1060×750	80-140	630	110-320	90-110	29
PE900×1200	900×1200	95-165	750	220-450	110-132	52
PE1000×1200	1000×1200	195-265	850	315-550	110	57
PE1200x1500	1200x1500	150-300	950	400-850	220	82.5
PEX150×750	150x750	18-48	125	5-16	15	3.8
PEX250×750	750×250	25-60	210	15-30	22-30	5
PEX250×1000	1000×250	25-60	210	15-50	30-37	7
PEX250×1200	1200×250	25-60	210	20-60	37-45	8.5
PEX300x1300	300x1300	25-60	250	20-120	75	11







...
