2013 hot sale! TDTG series small bucket elevator parts

Specifications

small bucket elevator
1.High-efficient elevator
2.CE,GOST,SGS approved
3.Supply assessment
4.One year warranty



2013 hot sale!  TDTG series bucket elevator parts

Features



1. It has compact structure and small overall dimensions of transect and floor space can be saved remarkably;

2. Head: Rubber covering technology is adopted for head pulley to increase friction coefficient and improve the driving efficiency; Height of discharging section of head is increased, thus extending the materials discharging time. And it is fitted with outlet adjusting plate and buffer chamber to effectively reducing the returning of materials; The housing is lined with replaceable UHMW wear proof materials;

3. Middle Casing: The edge meshing technology is adopted, resulting in high strength and good tightness; The balancing pipe is added to balance the pressure between two housing of machine body; Wide opening access door facilitates the repair and replacing of bucket; Explosion- proof port is available and can effectively reduce pressure and release explosion;

4. Foot: New type shaft sealing structure prevents dust from leaking; Split structure of bearing housing guarantees the reliability of use of machine; Two sealing devices in the adjusting plate prevent the dust and materials from  leaking out of the adjusting plate;

5. The machine is fitted with anti-reverse device so as to avoid the blockage caused by power failure;

6. Speed detector and off track alarm sensor are optional;

7. It can be used for granular, powdery and blocky materials vertical conveying and widely used for feed mill, oil plant, food, chemicals, construction materials, grain warehouse and port.



Main technical parameters



Model(TDTG) Parameters		36/13	36/18	36/23	36/28	50/23	50/28	60/30
Output(t/h)	Granulate	8	15	20	25	35	45	65
	Mash	5	12	18	20	25	25	35









Animal feed production line

Production Sequence

 1. Receiving and pre-cleaning Process

 2. Grinding Process

 3. Proportioning and mixing process

 4. Pelleting Process

 5. Sifting and cooling Process

 6. Bagging Process







Delivery process





Company introduce

    Liyang City Rongda feed Equipment Co., Ltd., was established in January 2005, is located in the superiorinvestment environment in Tai Tau Industrial Area,covering over 25,000 m2, building area of more than 13,000 square meters, office building covers an area of?more than 500 square meters.
   The Rongda company is the one for many yearsspecialized in biomass.....

Certificate





FAQ:





1.Q:Are you a factory or trading company?
A:We are a factory .





2.Q:Where is your factory located? How can I visit there?
A:Our factory is located in Liyang City, Jiangsu Province, China.

All our clients, from home or abroad, are warmly welcome to visit us!





3.Q:How can I get some samples?
A: We are honored to offer you illustrated catalogues.





Why buy from us?

1.Highest quality and most competitive price----we are the only one manufacture who adopts import raw materials. Low bad rates, is just 0.1%. It is amazing, and with cheap price and guaranteed quality.

2.Delivery fast -----Goods be sent out within 15 to30 days based on order quantity.

3.Professional-----We are special in source and sells, as development, methods, conjugations, and handling.

4.Best service-----Answering e-mails or solving questions timely. Delivery and update information on time. Trust, good quality and service are the basic of long term business.
