SSHJ4 stainless steel premix mixer

Specifications

Double shaft mixer
1.High-efficient machine
2.CE,GOST,SGS approved
3.Supply assessment
4.One year warranty



SSHJ4 stainless steel premix mixer

   We are specialized in designing and manufacturing poultry feed,aquatic feed pellet machinery,biomass pellet machinery and the complete production line(all auxiliary equipment) with CPM advanced technology.



   The current products include: hammer mill, ingredient weighing system, mixer, pellet mill, counter-flow cooler, dryer, crumbler, rotary screener, liquid adding equipment, pulse filter equipment, horizontal and vertical conveying equipment, links and gates, permanent magnet cylinder, and de-iron equipment etc.



SSHJ series double shaft mixer



Features:

1.The mixing chamber is constituted by twin screw and atomizing system. The filling seal is adopted for ends of shaft to improve tightness and prevent from leakage.

2.Specially designed discharger has big door-opening angle and quick discharging with less residue.

3.Good tightness and no leakage.

4.Pneumatic or Electric driven discharging is uses with correct, stable move and good tightness.



SSHJ4 details

Volume: 4m³

Mixing Amount per Batch : 2000kg

Mixing time per batch: 30-120s

Mixing homogeneity: 3-5

Power: 30/37kw



Item   Model	Volume m3	Mixing Amount per Batch(kg)	Mixing Time Per Batch(s)	Mixing Homogeneity (cv≤%)	Power(kw)
SSHJ 0.5	0.5	250	30-120	3-5	7.5
SSHJ 1	1	500	30-120	3-5	15
SSHJ 2	2	1000	30-120	3-5	18.5
SSHJ 4	4	2000	30-120	3-5	30
SSHJ 6	6	3000	30-120	3-5	37
SSHJ 8	8	4000	30-120	3-5	45







SLHY single shaft mixer



Feed equipment line

Production Sequence

 1. Receiving and pre-cleaning Process

 2. Grinding Process

 3. Proportioning and mixing process

 4. Pelleting Process

 5. Sifting and cooling Process

 6. Bagging Process















Delivery process







Company introduce



    Liyang City Rongda feed Equipment Co., Ltd., was established in January 2005, is located in the superiorinvestment environment in Tai Tau Industrial Area,covering over 25,000 m2, building area of more than 13,000 square meters, office building covers an area of?more than 500 square meters.
   The Rongda company is the one for many yearsspecialized in biomass.....





Certificate









Why buy from us?
1.Highest quality and most competitive price----we are the only one manufacture who adopts import raw materials. Low bad rates, is just 0.1%. It is amazing, and with cheap price and guaranteed quality.
2.Delivery fast -----Goods be sent out within 15 to30 days based on order quantity.
3.Professional-----We are special in source and sells, as development, methods, conjugations, and handling.
4.Best service-----Answering e-mails or solving questions timely. Delivery and update information on time. Trust, good quality and service are the basic of long term business.
