sunflower oil refining machine rice bran mill plant refined cooking oil machine for sale

Mian products:

1.Solvent pumps: continuously spray solvent to the rotary-type extractor
2.Roary extractor: Spray and soak the pre-pressed cake with solvent so that oil fats can be dissolved in solvent (form miscella).
After processing,you can get wet meal and miscella (mixed oil).
3.DTDC: used to separate the solvent from the wet meal.
4.Miscella tank 1st: pump the miscella (oil with solvent) in to the miscella 1ist , and then add 10% saline water to it. The phospholipid and impurities in the miscella will react with the saline wter, at last the reactant precipitate, reaching the goal of purifying.
5. Miscella tank 2nd: the purified miscella will be pumped into it.
6. Miscella stripping: it will remove the remaining solvent in miscella. And the solvent will be discharged to condenser for recycling.
7. condensers: used to cooling the solvent gas separated from the wet meal and miscella for recycling.

Workshop details:

leaching (extraction), evapo-separate (embryos solvent material separation), evaporation (oil and solvent separation), condensation, exhaust gas recycling, water recovery and other systems.

Working principle:

Leaching system is an oil extraction through soaking or spraying prepressed cake by a certain organic solvent. The principle of this part is the different solubility of solvent.

Main process:

(1) The material (for pretreatment) is sent to rotary extraction by the scraper conveyor. The material will extracted by the solvent or mix oil. After this step, we will get meal and mix oil.
(2) Meal is sent to toaster. Through the toaster, the solvent in the meal will separate from the meal. The solvent goes to condenser and is recycled to rotary extraction.
(3) After the mix oil from the rotary extraction enters into 1st evaporator and 2nd evaporator, most of the solvent in the mix oil is separated.
(4) The mix oil from 2nd evaporator goes to stripping tower and almost all the solvent is separated. From the stripping tower, we can get crude oil and solvent. The solvent is sent to condenser and is recycled to rotary extraction.

Picture Show

Packaging & Shipping

1.  Delivery: Ship

2.  Port:  Qingdao,Wuhan,Shanghai

3.  Packaging Details: Plywood, international standard trade packing

4.  Payment: L/C,D/A,D/P,T/T,Western Union,MoneyGram

Service Commitment

Company view

Our certificates

FAQ

Q1: What is the Warranty for the machines?
A1: 1 year for free.

Q2: What is the Material?
A2: Stainless steel and carbon steel.

Q3: When can I get the price?
A3: Within 24 hours, if urgent, please directly call us.

Q4: Whether the machine price can be more discount?
A4: In general, our MOQ is 1set with very reasonable price, but if large order, we also can apply to our Manager to appropriately give you a little discount.

Q5: How to ask quotation?
A5: Please note us what tpye of raw seeds , and how many tons of raw seeds you want to treat per day, then we will send you quotation as soon as we can.

Q6: Can we ask the oil plant for different types of oil?
A6: Yes, but we recommend no more than 3 different types.

Q7: Why need extraction?
A7: If only pressed, oil residue inside cake is very high at lease 6%. But after extraction, the oil residue will be less than 1%, which greatly increases the oil yield.

Q8: Vegetable oil plants require how large of a workspace?
A8: The land area typically depends on the capacity of the plant. We can suggest an appropriate space to prepare after given specifications, or, can design the oil plant in-house specifically to the amount of workspace available.

Q9: How long will it take to receive my products?
A9: As a general rule, it will take one Month for us to produce.

Q10: Do you offer oversea installation?
A10: We'll send professional installation engineer to help you install the equipment, as well as training your workers freely.

Q11: Can I visit your factory to check the machines and talk with your engineer?
A11: Yes,of course,welcome for coming!!

Our Advantages

• Some of our technology adopts Germany standard, and some equipment parts are imported
• Our stainless steel and carbon steel are all purchased directly from the steel factor with high quality we can guarantee the quality.
• All of our welding technicians have the employment certificates and with many many years experience.
• We provide installation ,commissioning, training and other oversea services.
