Electric Stacker Price Pallet Stacker

Electric Stacker Price Pallet Stacker photo-1
Electric Stacker Price Pallet Stacker photo-2
US$ 1,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
Ungar
Model Number:
Ungar 4 way stacker
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shanghai, China
Brand Name Ungar
Model Number Ungar 4 way stacker
After-sales Service Provided Engineers available to service machinery overseas

 Electric Stacker Price Pallet Stacker

electric stacker price pallet stacker



Product description:



The stacker is an electro pneumatic machine commanded by a PLC that provides to stack the trays and containers out from the press and to load them stacked in columns.

It is controllable according to the demands of the cycle of production through an operative panel.



Advantages:

1. Desing for labor saving and production efficiency.
2. Stack trays and containers of different dimensions.
3. Easy to operate and adjust based on customize requirements.


 Auto container stacker
 Model:The UN-6010 is for 55Ton/63Ton/80Ton/110Ton,with 1 to 5 lanes
 Collector belt width600mm(45ton)/850mm(63ton)/1080mm(80ton)/1340mm(110ton)
 Collector belt heihgt1100+-100mm (According press machine's size, we will adjustable height system on requested)
 Min. container dimensions80 x 120mm(Smaller on request)
 Container dimensions450 x 340mm(1 lane) 230 x 340mm(2 Lines)
The lanes could be less or more on your condition, also depend on container shape.
 Max. height of container stack300mm(Depend on the container shape and size)
 Lifting systemBy step motor and linear guide
 Photocell electronic counting device Container counter automatically stops press at top of stroke in emergency situations.
 Control panelTouch screen panel
 Stacking systemPhoto electric sensor controls the height of the stack with electric brake system.
 Installed Power1Kw
 Air consumption(2lanes)0.1m3/Min
 Net.weight300kg
 Stacker dimensions(L*W*H)55ton:3200x1050x1400(+-100mm)mm; 63ton:3200x1300x1400mm;        80ton:3200x1530x1400mm;           110ton:3200x1790x1400mm
 Notice:The Stackers specifications depend on container size and shape and the mould cavities.







Company information:

electric stacker price pallet stacker



 electric stacker price pallet stacker





 UNGAR Machinery (Shanghai) Co., Ltd is an Austrian enterprise established in 2009, supplying high productive multi-cavity moulds and machines, which includes press, stacker, package, re-winder, paper lid cutting, decoiler, scrap press and additional equipments.



UNGAR complete integrated production line has been specially designed and developed for the production of aluminum foil food container, plate and household foil rolls.







UNGAR Machinery (Shanghai) Co., Ltd also offer customized service for technical optimization, mould prove, machine installation, material test, training course, telephone assistance and so on.
