63T Automatic Foil Container Stacker Machine (UNST-6010-63T)
The Stacker is an electro pneumatic machine commanded by a PLC that provides to stack the trays and containers our from the press and to load them stacked in columns.
It is countrollable according to the demands of the cycle of production through an operative panel.
Advantages:
- Desing for labor saving and production efficiency.
- Stack trays and containers of different dimensions.
- Easy to operate and adjust based on customize requirements.
Detailed Informations:
| Model: The UNST-6010 is for 63Ton 1-5 lines available. | |
| Tonnage of the Production Line | 63 Ton Line |
| Collector Belt Width | 850mm |
| Collector Belt Heihgt | 1100 (±100) mm (The height is adjustable) |
| Min. Container Dimensions | 80 × 120mm (Smaller also available) |
| Container Dimensions | 450 x 340mm(1 lane) 230 x 340mm(2 Lines) The lanes could be less or more on your condition, also depend on container shape. |
| Max. Height of Container Stack | 300mm(Depend on the container shape and size) |
| Lifting System | By step motor and linear guide |
| Photocell Electronic Counting Device | Container counter automatically stops press at top of stroke in emergency situations. |
| Control Panel | Touch screen panel |
| Stacking System | Photo electric sensor controls the height of the stack with electric brake system. |
| Installed Power | 1Kw |
| Air Consumption (2lanes) | 0.1m3/Min |
| Net.Weight | 300kg |
Stacker Dimensions (L*W*H) (mm) | 3200×1300×1400(±100) |
| Notice:The Stackers specifications depend on container size and shape and the mould cavities. | |
UNGAR Machinery (Shanghai) Co., Ltd is an Austrian enterprise established in 2009, supplying high productive multi-cavity moulds and machines, which includes press, stacker, package, re-winder, paper lid cutting, decoiler, scrap press and additional equipments.
UNGAR complete integrated production line has been specially designed and developed for the production of aluminum foil food container, plate and household foil rolls.
UNGAR Machinery (Shanghai) Co., Ltd also offer customized service for technical optimization, mould prove, machine installation, material test, training course, telephone assistance and so on.
