maglev vertical axis wind turbine for residential use

FOB Price

USD $2,800 - $3,500 / Set

1 Set(Min.Order)

Supply Ability 200 Set / Sets per Month
Port Qingdao
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	Bofeng
Model Number	BF-H-2KW		Type	Wind Power Generator

Product Description

maglev vertical axis wind turbine for residential use

Model:BF-H-2K

Generator Type:Direct drive permanent magnet VAWT, 3 phase AC

residential vertical wind generatorPower(w):2000

Rated wind speed(m/s):9-11

Rotor diameter(m):2

Start-up wind speed(m/s):3

Height of blade(m):2.6

Range of working wind speed(m/s):3-25

Material of blades and numbers:Glass Fiber Reinforced Plastic/5

Survival wind speed(m/s):50

Rated rotor speed(m/s):200r/min

Output Voltage:AC48V

Speed regulation method:Electromagnetic control

Stop method:Electromagnetic brake

Wind energy utilized coeffeicent:30%-40%

Sweep wind area:3.14sq.m

Range of working temperature:-45 -60 centigrade

Suggested supporting battery:4pcs12v100ah

Tower type and height:Guy cable tower/8m

Material introduction:

wind turbine blades: We utilize high strength glass fibre reinforced plastic and epoxy resin to make blades.The wind rotor operate well(stably and quietly).This kind of new aerofoil is elaborately designed by aerodynamic and hydromechanical specialists(experts).It start-up wind speed(or cut-in wind speed)is very low,and the wind energy (rotor power)coefficient is very high.

Generator:It is made up of the superior high strength permanent magnetic material. The volume is small and the weight is light, the generating electricity coefficient is high.The generator specialist(expert) use special electromagnetic technology to make the generator have extremely low start-up drag torque, which can make sure the VAWT start-up in the gentle breeze.The generating electricity coefficient, start-up performance and overspeed overload capacity of generator are all in leading position in this field.

Controller:

IController Parameter:

Model	WWS20A-48	WWS20A-96	WWS20A-120	WWS20A-220
Rated Wind Turbine Power	2kW
Rated Solar Power	600W
Rated Battery Voltage	48V	96V	120V	220V
Wind Turbine Maximum Input Current	80A	40A	30A	20A
Wind Turbine Maximum Input Power	4kW
Unload Voltage(factory default)	56V	112V	140V	252V
Unload Current(factory default)	50A	25A
Control Mode	PWM
Display Mode	LCD
Display Parameters	Wind Turbine Power, Wind Turbine Voltage, Wind Turbine Current, PV Voltage, PV Charge Current, PV Power, Battery Voltage
Working Temperature &Humidity	-20~+50℃/35~85%RH(Without Condensation)
Temperature Compensation(optional)	4mV/℃/2V ,–35℃--+80℃, Precision:±1℃
Communication Mode(optional)	RS232,RS485,RJ45,GPRS. Etc
Protection Function	Solar reverse charge protection , Solar reverse connection protection, Battery over charge protection ,Battery reverse connection protection, Lightning protection, Wind turbine current limiting, Wind turbine automatic brake and manual brake.
In order to serve our customers better. Our company can adjust parameters configuration according to customer’s requirement.

Inverter:

Inverter Parameter:

Product Model	WI20-24-3N01
Rated Output Capacity	2kVA
Rated Battery Voltage	48VDC
Over Voltage Shutoff	66VDC
Over Voltage Recovery	42VDC
Under Voltage Shutoff	48VDC
Under Voltage Recovery	48VDC
No-load Loss	≤0.35A
Output Wave	Pure sine Wave
Display Mode	LCD
Cooling	Fan
Rated Output Voltage	220VAC
Wave Distortion	≤4%
Output Frequency	50±0.5Hz
Dynamic Response	5%
Power Factor	≥0.8
Over-load Capacity	120% 1min,150% 10s
Invert Efficiency	90% Max
Isolating Mode	Toroidal Transformer
Noise (1m)	≤40dB
Insulating Strength	1500VAC,1min
Protection Functions	Input over voltage protection, Battery under voltage protection, Battery anti-reverse connection protection, Output overload protection, Output short circuit protection, Over temperature protection.
Ambient Temperature	-20~+55℃
Working Altitude	≤4000m
Ambient Humidity	0~90%,Without Condensation
Dimensions (Lx W x H)	402×163×202mm
Net Weight	12kg
In order to serve our customers better, our company can adjust parameter configuration according to customer’s requirement.
