KD Designed Hot Sale And Low Price Pumping Dredger

Specifications

KD Designed Hot Sale And Low Price Pumping Dredger
1.Cummins engine
2.With patent
3.Good after-sale service
4.PLC control

China  Manufacturer Pumping Dredger For Sale





1. Pumping Dredger  Specification is as follows:

==========================================

• The pump sand dredger is eqipped with a quick connection and dismantle  system by road rail or water,achieved using bolts at deck level,and hook at the bottom.
• The dreger can be used to excavate and transport cohesive sediemnt.We have considerad special requirement for tropical climate conditions
• Further salient features of the vessel are the compact dredge pump drive incorporating a reduction gear with integrated pump bearing and a fresh water engine cooling system, based on the well cooling principle.





2.Pumping Dredger  Parameter:

==============================

Model	KDSX200-10	KDQSB200-5
Dredger Body
Dimention (m) L*W*H	14*4.2*1.4m	12*4.7*1.2
Float
Pontoon
Side pontoons 2sets	11.5*1.0*1.4m	11*1.25*1.2
Main pontoon 1set	8.5*2.25*1.4m	8*2.25*1.2
Material	CCSA	CCSA
Total weight T	30	20
Pump model	6/4”D-G	ZJQ300-20-37
Rotation speed(r/m)	1150	980
Dredging data
Standard dredging depth	8-10m	5m
Standard discharge distance	500m	50m
Max.dredging depth(m) (optional)	10m	8m
Max.discharge distance (m) ( medium and fine sand<0.235mm when min.flows)	600m	70m
Max.standard dredging capacity   m3/h	50m3/h	50-70m3/h
Min.clean water flows(standard dredging depth and Max.discharge distance)	250m3/h	300m3/h
Suction pipe diameter(mm)	200
Discharge pipe diameter(mm/inch)	200	200mm



Our company- Pumping Dredger  manufacturer:

======================================

1)We are one professional manufacturer and exporter of hydraulic cutter suction dredger and some related products.



2)we had established good cooperation with Import and export trading company, established Shandong magnetic equipment Research Instituting. We have CAD Aided Design R & D center and physical mineral processing laboratory,can work out reasonable and practical solution according to customer's technical requirements and work site,also had established and improve the equipment file and service system, concentrating on customer feedback to make the products constantly improved  to meet the customers' different needs.



3)The dredger has passed ISO quality system certification and Chinese Classification Management System Certification with good quality and low price.





Clients come to visit our factory



In order to decrease the deliver time, we will make some ready or semi-product in our workshop.



Welcome all of you to our factory and check the products first.

Begin to produce the Sand Pumping Dredger  according to the clients' request



After signed contract and received the first payment, we will begin to produce equipments according

to the clients' order.



Pumping Dredger Testing Before Shipping:



After finished the dredger, we will do water test and check the operation and working capacity of

the dredger.



Pumping Dredger Transporting of the spare parts:



Once we confirmed all functions of the dredger are ok, we will disassamble the dredger andtransporting it to the port at the clients' side.





Details of  Pumping Dredger









Pumping Dredger Pump



More information,please don't hesitate to contact me
