Home > Products > Oil Press Machine > 50-100kg/h Hydraulic Cold Press Oil Extraction Machine
50-100kg/h Hydraulic Cold Press Oil Extraction Machine
- 500 Set / Sets per Month
- Port in China
- T/T D/P D/A Credit Card PayPal
Product Details
| Condition: | New | Usage: | Other, peanut, beans, rape and cotton seeds, sunflower, coconut, grass seed | Type: | Other, Cold & Hot Pressing Machine |
| Automatic Grade: | Automatic | Production Capacity: | 100% | Place of Origin: | Shanghai, China |
| Brand Name: | BETTER | Model Number: | HOP-95A 50-100kg/h Hydraulic Cold Press Oil Extraction Machine | Voltage: | 380V |
| Power(W): | 7.5KW-11KW | Dimension(L*W*H): | 1800*900*1550MM | Weight: | 550 KG |
| Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
50-100kg/h Hydraulic Cold Press Oil Extraction Machine
Introduction of 50-100kg/h Hydraulic Cold Press Oil Extraction Machine
The HOP-95A screw oil expeller are advanced screw expeller pressing, characterized by their high oil output rate with good quality, simple design, easy to use and continuous operation. HOP-95A screw oil miller can be used to press various raw material, such as peanut, beans, rape and cotton seeds, sunflower, coconut, grass seed etc. Gearbox uses helical gears, making smooth transmission, and reduce operating noise.
Working principle of 50-100kg/h Hydraulic Cold Press Oil Extraction Machine
HOP-95A screw oil miller utilizes the screw that us set-up with different styles of screws and rotates when machines is running to push the materials into chamber. Owing to the spiral helical pitch of screws becomes shorter and the spiral depth of screw. Becomes shallower, in the chamber the volumes between screws and pressing ring inner is smaller, pressure produced from curve saw-tooth of pressing ring inner, which oil is separated out. Oil releases from the gaps between bars and oil slots between pressing rings. Cookie releases from the cookie releases state.
Technical parameters of 50-100kg/h Hydraulic Cold Press Oil Extraction Machine
MODEL | CAPACITY(T/24h) | POWER(kw) | NET WEIGHT(kg) | PACKING(mm) |
HOP-85A | 1.4-2 | 5.5 | 200 | 900*400*1200 |
HOP-95A | 3.5-5 | 7.5-11 | 550 | 1800*900*1550 |
HOP-105A | 5-7 | 11-15 | 600 | 1925*900*1550 |
HOP-130A | 10-12 | 18.5 | 820 | 2010*800*1380 |
HOP-150A | 18-20 | 30 | 1420 | 2230*660*1000 |
BETTER Highlights
1.Full production line including Machining Line, Polishing Line and assembling line etc.
2.More experience in exporting business.
3.Innovation is the key to the development of our enterprise.
4.Systematic Management applied.
5.Excellent export team allow BETTER to respond customers quickly and on time delivery.
6.Manufacturing capacity up to 150sets Per Month.
7.Well equipped with modern test machines insuring reliability and endurance of products.
8.Skilled engineers and workers
The small cold press oil machine hydraulic oil press can press all kinds of oil seeds, like oliver seeds, palm seeds, sunflower seeds,peanut,soybeans,rapeseeds, almond seeds,coconut seeds, pumpkin seeds oil press, etc.With cold & hot system.
What does BETTER need from me to quote a price?
1.What is your raw material?
2.What is your capacity?
Our smallest capacity is 1.4~2Ton/24 hours,and biggest capacity is 18~20Ton/day.
What material does your machine can process?
Peanut,beans,rape and cotton seeds,sunflower,coconut,grass seed etc.
What quality of oil can we get from your machine?
Crude oil.
What is the oil yield?
It depends on oil content of your material.If the oil content of your material is
high,you can get more oil.
Does your machine do “cold press”?
Yes.Hot press and cold press we supply.Usually hot press can get more oil than cold
Press.
Can you do press test for us before purchasing?
Yes,we can press your raw material if we have machine in stock.
Does your machine can press different raw material?
Yes,it does.
Can you do refine?
Yes,we can do refine oil according to your request.We have 4 grade,from “A”to “D”(Based
on Chinese Food grade oil standard)
Do you have machines in stock?
Yes,we have.If we have no machine in stock,it usually takes about 20days to produce.
How will my order be packed, can you provide the installation service?
The machine will be packed in plywood case and we will assemble and test the machine
before packing. Also send English manual.
Why Choose BETTER?
1.We are Alibaba Assessed 6 years Gold Supplier.
2.We are a factory manufacturing food machine, best production capability, best quality control, best Service.
3.Inspected by the Inspection Institution of Bureau Veritas Certification.
4.100% QC inspection Before Shippment.
5. CE listed,competitve price.
Send your Inquiry Details in the Below, Click "Send" Now! Specific information and Accurate quotation
are waiting for you.
