ISO electric motor rock breakers for sale
- 15 Set / Sets per Month
- Qingdao Tianjin Shanghai
- T/T
Product Details
| Condition: | New | Type: | Other, mining crusher | Application: | Mining |
| Motor Type: | AC Motor | Power(W): | 15kw | Capacity(t/h): | 5-20tph |
| Place of Origin: | Henan, China | Brand Name: | Hongke | Model Number: | Models |
| Dimension(L*W*H): | 1150x1275x1240mm | Weight: | 2.8t | Certification: | ISO9001:2008 |
| Warranty: | 12 Months | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
Standard export package,suitable for sea shipping
Product Description
Introduction
weare professional provide all kinds of breaker/breaking machine,suitable for many industries such as ore crushing, railway, highway, energy, cement, chemistry and constriction. The size of the discharging granularity is adjustable with diverse crushing specifications.follow just as impact crusher as an example ;
Working principle
impact crusher is a kind of crushing machine which utilizes impact energy to crush
materials.
Its working principle is as follows:
Driven by the motor, rotors rotate at a high speed. The hammers on the rotor also rotate at a high speed. When the materials are firstly crushed by hammers, then thrown to
the impact plate for secondary crushing, and then reboundedand crushed again by hammers. This pattern is repeated until the materials are completely crushed to the desired size,and then the materials are discharged through the outlet.
The granularities and shapes of finished materials can be changed by adjusting the gap between impact frame and rotors.
Features
2. The gap between the impacting plate and the plate hammer is convenient for adjustment so that it can effectively control the discharging granularity with good particle shape.
3. It has compact structure and strong rigidness, and the rotational inertia of rotor is very big.
4. High chromium plate is adopted so that it has shock resistance, abrasion resistance and big impacting force.
5. No key links is adopted for convenience of maintenance and repair. In addition, it is very economical and reliable.
6. It is featured with comprehensive crushing, high production ratio, small abrasion and high comprehensive benefits.
| Model | Specifications (mm) | Feed opening (mm) | Max.feeding side length (mm) | Capacity (t/h) | Power (kw) | Total weight (t) | Dimensions ( L×W×H) (mm) |
| PF-1007 | Φ1000×700 | 400×730 | 300 | 30-70 | 45 | 12 | 2330×1660×2300 |
| PF-1010 | Φ1000×1050 | 400×1080 | 350 | 50-90 | 55 | 15 | 2370×1700×2390 |
| PF-1210 | Φ1250×1050 | 400×1080 | 350 | 70-130 | 110 | 17.7 | 2680×2160×2800 |
| PF-1214 | Φ1250×1400 | 400×1430 | 350 | 100-180 | 132 | 22.4 | 2650×2460×2800 |
| PF-1315 | Φ1320×1500 | 860×1520 | 500 | 130-250 | 220 | 27 | 3180×2720×2620 |
| PF-1520 | Φ1500×2000 | 830×2040 | 700 | 300-550 | 400 | 50.6 | 3959×3564×3330 |
fixed international standard package ,by sea delivery is safe and reliable ,suitable for oversea shipping .
Henan hongke heavy machinery Co.,Ltd is located in zhengzhou city ,henan province .With about 20years experenced big machinery factory in henan province .Mainly specilized in all kinds of crusher,shredder ,rotary kiln,dryer ,grinding machine,mining machine and so on , won many domestic and foreign customer to visit and cooperate.
1,we will be at your service for 24 hours,any qustion and requirment just let us know .
2,we have technical guide and engineer help ,can give you best suggestion and help you solve your problem .
3,our after-sale service is long time for the machine ,anytime with pleasure to answer your question .
4,we provide machine sprare parts for free charge to our old customer and any new customer .
Q: Are your real manufacturer?
A: Yes,we have our own big factory ,anytime welcome your visiting .
Q: What do you have for machine installing ?
A: We have engineer for technical gudiance and oversea installing guide .
Q: How can you promise your product quality ?
A: We have about 20 years business experience,we got CE,ISO and so on for our products.but the most important we win our customer with our best quality and honest.
............
Any more question please contact with us and welcome your visiting at our factory .
Company Profile
Henan Hongke Heavy Machinery Co., Ltd. . is located in Henan Province which is the cultural base of the central area of China. We are a mining machinery manufacturing enterprise that integrates scientific research, production and marketing. We are a newly-risen dazzling star in China's machinery industry with the development of market economy.
Our manufactory is a high-tech enterprise that specializes in the research and production of rotary kilns, driers, and crushers. Our major products, for example, rotary kilns, Raymond mills, a series of crushers, stone crushers, and a series of screens, jaw crushers, hammer crushers, impact crushers, cone crushers, and sand making machines, rank highly in the domestic market and some products have reached international advanced level.
Due to decades of venture and the self-improvement of our staff, our company has developed well. Employing a large number of talents who are keen on innovation and enjoy a high level in outstanding scientific research and management in the industry, our company cultivates talents with strict disciplines and high efficiency in order to forge ahead together. In order to meet the needs of the development of our company and the market competition, we have built the first-class modern production and testing base, established a worldwide sales network, and provided considerable services for our respectable customers. We adhere to the pioneering ideas of "quality prospers our company", pursue the service tenet of "we satisfy our customers with our whole heart", and insist on the operation essential of "honest and good faith, and seek truths from facts". We have won honorable titles like Good Credibility of After-Sales Service, and our "Hongke" trademark has become a symbol of the reputation.
The quality is the life of our enterprise. Our company has modern scientific management, advanced production equipment and strict testing means to improve products. Our company will continue to uphold our concept, serve our nation sincerely, and rejuvenate our nation. We are willing to work together with friends from all over the world to create a bright future and flourish our national industry.
