Home > Products > New Products > granulator machine for ldpe
granulator machine for ldpe
- 21 Set / Sets per Month
- chongqing or shanghai
- T/T L/C D/P D/A PayPal
Product Details
| Condition: | New | Type: | Recycling Granulator | Capacity: | 3-10tons |
| Place of Origin: | Sichuan, China | Brand Name: | YZJ | Model Number: | YZJ-SJ |
| Material: | PP/PE | Screw Design: | Single | Voltage: | customerize |
| Power: | 50-180KW | Dimension(L*W*H): | 6500*4500*2000 | Weight: | 3-15tons |
| Certification: | CE&ISO&SGS | Warranty: | 13 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Go to homepage You could download the <<Supplier Assessment Report>> of our plant release by SGS！
This Waste plastic granules making machine Main Technical Parameter:
Model | SJ-120 | SJ-140 | SJ-160 | SJ-180 |
Diameter of ScrewStem | 120mm | 140mm | 160mm | 180mm |
Major Diameter Ratio of Screw Stem | 12:1-22:1(L/D) | 12:1-22:1(L/D) | 12:1-22:1(L/D) | 12:1-22:1(L/D) |
Rationl Speed of Screw | 10-110rpm | 10-110rpm | 10-110rpm | 10-110rpm |
Main Motor Power | 22-30kw | 30-45kw | 37-60kw | 45-75kw |
Output | 60-150kg/h | 90-300kg/h | 110-400kg/h | 130-500kg/h |
Machine Weight | 2t | 2.6t | 3.7t | 4.3t |
Overail Dimensions(LxWxH) | 5800*4500*1100 | 5900*5300*1200 | 6000*5350*1300 | 6200*5400*1350 |
Product Detail
| Application | plastic recycling |
| Model number | double stage plastic granule machine |
| Other name | granulator |
| Design | single-screw extruder |
| Raw material | PP PET PE PS PVC ABS |
| product keywords | granulator machine for ldpe |
Features:
1.Output :150-500kg/h.
2. High-precision gearbox, high bearing capacity, smooth transmission, low noise.
3. New barrel and screw design, better melting, low-temperature melting and higher yields.
4. Screw and barrel could choose to be nitrogenized, resistant corrosion and wear.
Single screw extruder has the advantage of simple process, high output, stable operation, low cost, high bearing capacity.
Quality assurance:
1.CE;
2.ISO9001;
3.Alibaba trade assurance system.
security guaranteed 100%
Protect Your Payment, Secure Your Order
YZJ Machinery has acquired more than 100 patents in recent years and over 50 patents per year for its intensive operation several years. The company has been honored as :
1.The Leading Innovative Enterprise of Integrating Theory with Practice in China Plastic Machinery and Plastic Products Field
2.National High and New Technology Enterprise
3.Scientific and Technical Innovation Enterprise
4.Advantage of Growing Enterprise,
5.Intellectual Property Experimental Enterprise
6.Honesty and Integrity Taxpayer,
7.Hundred Million Enterprise
8.Advanced Enterprise of Project Construction etc.
FACTORY TOUR
YZJ is a professional supplier devoted to the designing & production of plastic machine and plastic product at the sametime over 21 years.
R&D
R&D team
21 Years
21 years experience
80,000 square meter
Factory
Plastic (pp pet) strapping band making machine,Waste plasitc recycling and granulator machine,plastic recygling machine,Waste plastic granulator,Plastic flakes crushing and washing line.
