High quality product . cement foaming machine

FOB Price

USD $4,500 - $15,000 / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port Qingdao

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Condition:	New	Place of Origin:	Henan, China	Brand Name:	YJY
Model Number:	YJY50	Motor Power:	22kw	Mixing Power:	2.2kw
Outline Dimension:	356015801590

Product Description

Specifications

foam concrete machine, foam concrete making machine
1.) ISO Certificate
2.) High quality product
3.) Competitive price .

Foam Concrete Machine

Features:

The foaming machine consist of the pumping system, foam generating system, mixing system, rack, electrical control cabinet.

(1) Pumping system: namely squeeze hose pump

(2) Foam generating system uses a standard modular structure, composed of frequency variable motor, air compressor, water pump, foaming agent gear pump, foam assembly etc.

(3) Mixing system includes the motor, mixing vat, mixer, transmission system, lubrication system etc.

(4) Electrical control system consists of the inverter, AC contactors, air switches, intermediate relay etc.

Working Process:

First, transport the cement into the mixing vat by the feeding machine.

Then, mix the cement with the water in the mixing vat by mixing machine.

Next, suck the mixed medium into the host machine by the squeeze pump.

Then, mix the cement slurry and the foam agent by the pump.

Last, pump the foam concrete to the target construction site.

Main Technical Data:

Item	Unit	YJY50
Theoretical production capacity	m3/h	50
Max. Pressure	MPa	4
Maximum horizontal distance	m	600
Maximum vertical distance	m	180
Total Power	kW	22
Dimension	mm	3560×1590×1580
