China wholesale 800W Far Infrared Radiant Electrical Heater

Specifications

Radiant Electrical Heater
1.Power:800W
2.Heating area:6-8M2
3.Technology:Anodicoxidation
4.Temperature:300 degrees

China wholesale 800W Far Infrared Radiant Electrical Heater



PUYANG Infrared Radiant heater is an electric home heater that is cost effective, maintenance free, and works in every room: bedrooms, kitchens, living rooms, sun rooms, and basements. Because Comfort Cove heating units are available in several different sizes, it's the perfect alternative home heater for a new or existing home, or remodeling projects. This electric radiant heat system is also an efficient heating solution for apartments, offices, workshops, schools, and medical facilities.





Specification:



1	Model	PF-NR08-11A
2	Output power	800W
3	Electric heater type	Infrared heater
4	Heating element	carbon fiber
5	Outer covering	Cold-rolled plate
6	Surface material	Aluminium alloy
7	Technology	Anodicoxidation
8	Temperature	230-270degree
9	Time	up to 300 degrees in 3minutes
10	Heating area	6-8m2
11	Installation	celling;wall mounted
12	Function	overheat protection;adjustable thermostat
13	Use	living room,bedroom,office,garden,factory, shop and so on
14	Size	860*270*75MM
15	Weight	8KG
16	Package	carton



INSTRUCTION METHOD

1. Product must be installed by professional installation personnel, and with national safety standards for electrical installation.
2. Rated voltage and power supply must use dedicated circuit, devices connected to the power outlet must have ground wire.
3. Determine the installation location of radiant heater, check the installation location can support four times of radiant heater weight, it should be reinforced before installation if can not support.
4. Choosing hanging rod bolts, fix 4pcs M8 screws on 4 positions of the bank radiant heater, as picture1.
5. Product can be installed on the ceiling/bracket or hanging installation. Be ensure that the space not less than requirements shown on picture2.
6. Please refer to wiring diagram.
