high efficiency coal ball briquette press machine for sale

Specifications

ball briquette press
1.free installation guide
2.4 rollers
3.high pressure
4.2 year quality guarantee time

Ball Briquette Press ,Charcoal Powder Forming Machine,Ball Press Equipment, Briquette Moulding Machine,BBQ charcoal machine,Coal Briquette Machine,Charcoal Powder Briquette Machine,Coal Ball Shaping Machine, Ball Press Machine



Product Description of Ball Briquette Press

Ball press machine is designed to press coal powder,sponge iron powder,sludge,kaolin clay,activated carbon , mill stone ,fgd gypsum , slag, fluorite powder,iron ore powder, calcined lime ,copper powder,manganese alloy,iron oxide skin,aluminum powder, manganic mineral, chromium ores powder and etc into all various shape briquettes with high density,the common ones are pillow/diamond(square)/oval,rectangle and ball shape as below





The briquette machine is widely used in refractory , metallurgy , chemicals and etc industries.



The finished coal briquettes has properties of high efficiency , energy saving and environment protection .

(the rate of coal saving :15-25% )

(smoke blackness reduced to 1/2 Ringelmann grade)

(55-75%sulfur fixation efficiency )



Working Principle of Ball Briquette Press



This series of briquette machine will pass the power on to the two pressure roller through the reducer.

The two sides and roll rotation, in both the rotating roll,Natural materials to enter the ball roll mode,

with the roll rotation, material pressure on a small become larger, When the material to the two rollers

rotating line contact point, the pressure of materials has reached the peak. Tremendous pressure in

the role of line, the materials become a finished product from the powder ball.



Auxiliary Equipment



Apart from the coal briquette machine , other related machine such as feeder, grinder, crusher and dryer are also available in our factory, it means we can offer a whole product line.





In order to give you the quotation in time,please tell me the answers of the following



question:



1.What's raw matarials?



2.The moisture and size of raw materials?



3.Capacity you need?



4.The shape and size of the final product you prefer?





Specifications





Model	Roller   Diameter	Power	Capacity   for coal fine	Capacity for   charcoal powder	Weight
TL-290	290mm	5.5kw	1-2   t/h	400-800   kg/h	750   kg
TL-360	360mm	7.5kw	3-5   t/h	800-1000   kg/h	1.5   ton
TL-430	430mm	15kw	6-8   t/h	1200-1500   kg/h	2.7   ton



 Remark: Based on different materials, briquettes’ size, capacity, the technical parameter is adjustable.



Working Procedure



If your raw material are charcoal powder, that is

charcoal powder(less than 5mm )->mix bonds to stir->press mixture into different shape

If your raw material are coal powder,that will be a little complicated

And if your raw materal is desulfurization gypsum , special compaction machine is needed .

So different raw material have to be equiped wih different flowchart ,also the layout is varioius according to the basic situation of your raw material , basically we can arrange 100t-500t Production line ,so if you have interests in our company, pls contact as the following info:

Details Photos
