Three seat type linear vibration screen
- 1200 Set / Sets per Month
- XiaMen/GuangZhou
- T/T
-
lWashing Plant trommel screen for Gold mining/Gold Ore Dressing Equipment/Beneficiation Equipment
-
Riddle Drum/Screening Washer/Separating Drum Screen/ Trommel / Trammel Screen/ Trommel Screen
-
SZZ double deck vibrating screen /China Vibrating Screen /Energy-saving Vibrating Screen
-
Condole type double deck vibrating screen/2011 hot high frequency efficiency vibrating screen
-
Condole type double deck vibrating screen/2011 hot high frequency efficiency vibrating screen
-
drum screen trommel screen/drum screen trommel screen
Product Details
| Condition: | New | Type: | Linear | Application: | Other, Ore, Ore |
| Place of Origin: | Jiangxi, China | Brand Name: | Oasis | Model Number: | YA\SZZ |
| Certification: | ISO9001:2008 | Weight: | 350-6300kg |
Product Description
YA,SZZ Vibrating Screen
YA, SZZ shaker widely used in mining, smelting, building material, highway, railway, water conservancy and chemical industry and many other sectors of the medium-grained materials, grading, dewatering, de-de or referred mud and operations.
This series of vibrating screen features are: simple structure, reliable operation and maintenance convenience, the user hanging when ordering please specify type and seat type
Model | Screen Layers | Screen Area | Feed size | Capacity | Opening size | Frequency | Power | Weight |
| Layers | m2 | mm | t/h | mm | r/min | kw | Kg |
600/1200 | 1 | 1.1 | 40 | 10-20 | 1-15 | 1000 | 2.2 | 350 |
600/1200 | 2 | 1.1 | 40 | 10-20 | 1-15 | 1000 | 2.2 | 360 |
900/1800 | 1 | 1.62 | 60 | 20-25 | 1-25 | 1000 | 2.2 | 550 |
900/1800 | 2 | 1.62 | 60 | 20-30 | 1-25 | 1000 | 3 | 620 |
1250/2500 | 1 | 3.13 | 100 | 150 | 3-30 | 850 | 5.5 | 1100 |
1250/2500 | 2 | 3.13 | 100 | 150 | 3-30 | 850 | 5.5 | 1300 |
1500/3000 | 1 | 4.5 | 150 | 220 | 5-40 | 800 | 7.5 | 2100 |
1500/3000 | 2 | 4.5 | 150 | 250 | 5-40 | 800 | 7.5 | 2300 |
1800/4800 | 1 | 7.5 | 200 | 450 | 6-50 | 360 | 15 | 6000 |
1800/4800 | 2 | 7.5 | 200 | 500 | 6-50 | 360 | 15 | 6300 |
