Stepless orbital MicroPlate Mixer

100-240

Frequency[Hz]

50/60

Power[W]

20

Shaking movement

Orbital

Orbital diameter[mm]

4.5

Max. shaking weight(with attachments)[kg]

0.5

Motor type

External rotor brushless motor

Motor rating input[W]

18

Motor rating output [W]

10

Speed range[rpm]

0-1500

Speed display

Scale

Dimensions[mm]

260×150×80

Weight[kg]

3

Permissible ambient temperature [°C]

5-40

Permissible relative humidity

80%

Protection class acc. to DIN EN60529

IP21

P/N

Description

822000010000

MX-M

Microplate Mixer, with PS1.2 adapter, Cn plug,110v/220v/50Hz/60Hz

822000020000

MX-M

Microplate Mixer, with PS1.2 adapter, Euro plug,110v/220v/50Hz/60Hz

822000030000

MX-M

Microplate Mixer, with PS1.2 adapter, UK plug,110v/220v/50Hz/60Hz

822000040000

MX-M

Microplate Mixer, with PS1.2 adapter, USA plug,110v/220v/50Hz/60Hz

Accessories

Cat No.

Description

18900067

PS1.1, Universal top plate,used with VT1.3.1--5

18900020

VT1.3.1, Tube adapter, for 48 holes test tubes, Ø6mm, used with VT 1.3/ VT 1.2/PS1.1

18900021

VT1.3.2, Tube adapter, for 18 holes test tubes, Ø10mm, used with VT 1.3/ VT 1.2/PS1.1

18900022

VT1.3.3, Tube adapter, for 12 holes test tubes, Ø12mm , used with VT 1.3/ VT 1.2/PS1.1

18900023

VT1.3.4, Tube adapter, for 8 holes test tubes, Ø16mm,  used with VT 1.3/ VT 1.2/PS1.1

18900024

VT1.3.5, Tube adapter, for 8 holes test tubes, Ø20mm, used with VT 1.3/ VT 1.2/PS1.1

18900042

PS1. 2 Adapter
