High efficiency bean stalk Carbonization Furnace the whole process does not produce harmful gases

Tech parameters of Carbonization Furnace

Two types carbonization furnace are provided: Horizontal Continuous Carbonization Furnace and Vertical Continuous Carbonization Furnace.

1.Horizontal Continuous Carbonization Furnace

2.Vertical Continuous Carbonization Furnace

Intorduction of Carbonization Furnace

     Carbonization furnace, Shanghai Manda Dynamic Technology Co., Ltd. is a professional to create superior quality, with a unique manufacturing process, perfect after sale service, reasonable price, excellent quality of equipment. This product is also applied for the national patent, the equipment to meet market demand, the construction of the national service better, to meet the needs of customers.

     Carbonization furnace is an efficient energy saving and environmental protection equipment of carbonization, the carbonization equipment suitable for sawdust, rice husk and other fine powder shape, not easy for larger material by carbonization furance, advanced technology, is the whole process does not produce harmful gases, pollution of the environment.

     The carbonization device is peanut shell, wood, corn stalk, rice husk, bagasse, twigs, bamboo shavings, sorghum stalks, sunflower seed shell, lees, corn cob, sorghum stalk, coconut, coffee grounds, cotton stalk, bean stalk, potato grass, dead leaves and other waste as raw material, made by high temperature high quality, environmentally friendly and efficient mechanism of charcoal or charcoal powder. Carbon materials clean carbonization equipment produced non-toxic, high heat energy, sell well in the market, broad prospects.

 Advantages of Carbonization Furnace
1. the carbonization time is short, high efficiency, high production rate.
2. smokeless and dustless, environmental products.
3. simple operation, saving time and labor, without any risk.
4. product quality assurance, the carbonization rate was 100%, charcoal powder is not broken, good looks, the pioneering technology, this product is a patented product.

Features of Carbonization Furnace
1. The combustible gas made by self generated flue gas can be used recycling, gasifier slag can be used as charcoal powder, direct sales, to achieve the effect of energy saving.

2. The whole process without flue gas emissions, meet the national environmental protection requirements.
3. Carbonizing out the maximum yield of charcoal in the shortest time, each furnace carbonization time only need 4-6 hours.
4. 1-2 people can operate the whole production line, each furnace volume 13 cubic meters, high production and efficiency.

5. By-products:wood tar refining diesel oil, wood vinegar liquid can be used as pesticide, will waste to exploit to the greatest extent, no waste.
6. The finished charcoal powder can reach 600Kg/h.
7. None stoping,working for 24 hours.
8. Environmental protection,burn the furnace smoke itself,so no smoke go out.

Working principle of Carbonization Furnace
1. Drying stage
    From the start, to slowly rise to 160 degrees Celsius temperature carbonization, the bar containing water mainly depends on the external heat and bar produced by the combustion of evaporation. Fuel rod chemical composition has hardly changed.

2. Initial stage of carbonization
    This stage mainly depends on the bar self combustion heat, the carbonization temperature rises to 160 to 280 degrees Celsius temperature.
    At this time, the lignin material thermal decomposition reaction, which began to change. The unstable components, such as semi cellulose decomposition of CO2, CO and a small amount of acetic acid and other substances.

3. Comprehensive carbonization stage
    At this stage the temperature is 280 to 400 degrees Celsius temperature, at this stage, the lignin material rapidly for thermal decomposition, and generate a lot of acetic acid, methanol and wood tar and other liquid products. In addition to producing methane, ethylene and other combustible gas, the combustible gas combustion in the furnace. The thermal decomposition and combustion gas generated a lot of heat, the furnace temperature is raised. Wood materials under high temperature pyrolysis char.
