Beam Saw HC 45/3000Z
- 1 Set / Sets per Month
- Qingdao
- T/T
You May Like
Product Details
| Type | Table Panel Saw | Use | Woodworking | |
| Style | Horizontal | Place of Origin | Shandong, China | |
| Brand Name | Haiyiong | Model Number | HC 45/3000Z |
Product Description
Specifications
* CE & CSA* Motorizing up/down
* 5.5Kw motor, 350mm, Freud / AKE
* Heavy duty dust hood
Function description:
1.Fit for processing various panel with similar rigidity, such as consistent plate, flake board, manmade plate, ABS plate, PVC plate, organic glass plate and solid wood;
2. Guide rail of mobile workbench is made of imported chrome plated round stick with high rating accuracy;
3. Surface of mobile workbench is made of high intensity extruding aluminum alloy with high intensity and no deformable performance;
4.Surface of mobile workbench passes treatment of oxidation, beautiful and wearable;
5. Obliquity of principle saw blade and scoring saw blade is directly displayed by precise inclinometer.
Technical specification:
Model | HC 45/3000Z |
Dimension of sliding table | 3200*360mm |
Gross cut capacity | 3200mm |
Width of cut between saw blade and rip fence | 1250mm |
Saw blade diameter | 300mm(φ250-φ350) |
Height of cut | 80mm |
Height of cut with saw blade at 45° | 55mm |
Speed of main saw spindle | 4000/6000rpm |
Main spindle diameter | 30mm |
Tiling saw blade | 0-45° |
Main motor | 4/5.5kw |
Scoring saw blade diameter | 120mm |
Speed of scoring saw blade | 8000r/min |
Scoring spindle diameter | 20mm |
Scoring motor | 0.75kw |
Net weight | 640kg |
Gross weight | 790kg |
Overall dimension | 3250*3250*900mm |
