Home > Products > Coal/charcoal balls pressing machine > Good sell and best service Dry powder press machine
Good sell and best service Dry powder press machine
- 80 Set / Sets per Month
- Qingdao Shanghai Guangdong or other inland custom port
- T/T L/C D/P D/A Credit Card
- China made good quality and low price Dry powder briquette machine
- Popular type manufacturer of Dry powder ball press machine
- 30 years experience High pressure High pressure dry powder ball press machine
- Mechanical/Hydraulic Energy Saving Olive charcoal briquette machine
- coal/charcoal powder briquette ball press machinery
- Coal Pulverized machinery of best factory low cost
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | henan meshen machine |
Model Number: | CE | Voltage: | 220v, 380v, etc | Power(W): | 11kw, 15kw, 18.5kw, 22kw, etc |
Weight: | Accoeding to your type | Dimension(L*W*H): | Accoeding to your type | Certification: | CE ISO |
Warranty: | One year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Good sell and best service Dry powder press machine
Specifications
High pressure dry powder ball press machine
1.scientific design and stable structure
2high quality
3complete structure machine
4.low investment and high profit
1.Description of High pressure dry powder ball press machine
High pressure dry powder ball press machine, also known as goose machines, Dry powder ball press machine,mainly used to press some difficult molding powder materials , characterized by forming pressure, the host rpm adjustable , with a spiral Feeding Device. Dry powder briquette machine can be used to suppress coal , iron , coke , aluminum powder, iron , iron oxide skin, toner , toner , slag , gypsum, tailings , sludge , kaolin , activated carbon, coke powder and other end , Powder , waste, waste residues, are widely used in refractory , power plants , metallurgy , chemical , energy , transportation, heating , etc , produced by the compression Dry powder press machine after the ball materials , energy saving , easy to transport , increase of wastes Utilization, with good economic and social benefits.
At the beginning, there are two rollers of this briquette machine. Recenely years, to improve roller pressure and increase briquettes hardness, we designed 4 rollers briquette machine(hydraulic type), which adopts molding twice strategy. So the finished briquettes have high hardness, even down from 3 meters height, no shattered.
Working principle: this series briquette machine pass power materials onto two pressure rollers through the reducer, then two rollers rotate to two sides, so materials naturally enter the roller molds, with the rollers rotation. When the material reach the two rollers rotating line contact point, the pressure of materials has reached the peak. Tremendous pressure in the role of line, the materials become a finished product from the powder ball.
Types we have as follows, if you can share me your raw materials and capacity demands, I will suggest suitable type for you.
2.Main parameter of High pressure dry powder ball press machine
Type | Capacity (t/h) | Roll Diameter (mm) | Pressure(t) | Roll Speed (r/min) | Power (kw) | Reducer |
MC-290 | 1.5-2 | 290 | 18-20 | 15-17 | 5.5 | ZQ290 |
MC -360 | 2.5-3.5 | 360 | 20 | 15-17 | 7.5 | ZQ360 |
MC -400 | 4-5 | 400 | 22 | 15-17 | 11 | ZQ400 |
MC-500(1) | 6-8 | 370 | 24 | 15 | 15 | ZQ500 |
MC-500(2) | 8-10 | 500 | 25 | 15 | 22 | ZQ650 |
MC -650 | 10-15 | 650 | 30 | 15 | 30 | ZQ650 |
MC -750 | 15-20 | 750 | 34 | 13 | 30 | ZQ750 |
MC -850 | 25-30 | 850 | 54 | 13 | 37-45 | ZQ850 |
MC 1000(1) | 35-40 | 1000 | 60 | 12 | 45-75 | ZSY-355 |
MC 1000(2) | 35-45 | 1000 | 77-240 | 10 | 75-90 | ZSY-400 |
Shape and size of final briquettes: square, ball egg-shaped, round, oval, and column, strip-type, elliptic type, pillow type and other special shapes by customizing the matching molds. Usurally 20-60mm. |
3.The molds
4.Characteristics of High pressure dry powder ball press machine
1. The roller is made by hard materials with good wear resistance and long life time
2. Smokeless and long-burning time.
3. The end outlet shape of products can be all shapes
4. The products have high density, high strength, and high hardness
5. Dry powder ball press machine is mainly used for no water portion of the material made of ball pressure.
6. It adopts advanced technology, which makes the final products have reliable quality
5.Shape and size of final product
6.The complete production line of Dry powder briquette machine
Raw materials--> Charcoal crusher --> Wheel mixer and liquid mixer --> Feeder --> Charcoal briquette machine --> Dryer.
7.Packaging & Shipping of High pressure dry powder ball press machine
Our Services
1.Pre-sale services:
According to your special needs, design and manufacture products for you, provide you with project design, process design, purchase program suitable for your machines and equipment.
2.Sale of services:
Assist you to complete acceptance of the equipment, and the construction program and detailed process
3.After sale service:
the factory sent technicians to teach how to install the equipment, commissioning and training of operators.
