2.5T Henan Yigong Movable Hydraulic single post car lift
- 250 Set / Sets per Month
- Qingdao Shanghai Tianjin
- T/T L/C D/P D/A Credit Card
Product Details
Design: | Single Post | Type: | One Cylinder Hydraulic Lift | Certification: | Other, ISO |
Lifting Capacity: | 2500kg | Lifting Height(mm): | 1950mm | Overall Width(mm): | <1800mm |
Place of Origin: | Henan, China | Brand Name: | Yigong | Model Number: | YG-CL1 |
Warranty: | 12 Months |
Packaging Details
the hydraulic single post car lift car packaged into standard wooden box, which can meet the long term transportation
Product Description
2.5T Henan Yigong Movable Hydraulic single post car lift
1. Technical Parameters:
Models | WX-1-2500A |
Lifting capacity | 2500KGS |
Lifting height | 1950mm |
Motor Power | 2.2kw |
Lifting time | 60S/30S |
Overall size | 2060 x 1300 x 2600mm |
Operating Temperature | -5℃~+40℃ |
Power supply | 110v/220v/380v,1ph/3ph |
Weight | 700KG |
Package | stell power unit packed with strong plywood box.
|
Packing size |
|
Shipping: | 36 pieces / 20’ container |
2. Features:
Which machine is suitable for motor transport company, medium and small repair shop, special station, maintenance center and tire stores such as car repair industry. This machine is mainly used for 2 tons the following all kinds of cars, light vehicle maintenance and repair when lifting. The machine USES electrohydraulic combined control, high degree of automation, simple operation and easy to use, safe and reliable, has small volume, portable, save space and so on.
1.Space saving single post design can be positioned either to give complete free access to the driver’s door.
2. Single hydraulic Cylinder.
3.Heavy-duty leaf chain.
4.Freestanding design
5.Durable construction for maximum stability.
6.Mechanical safety device against the accidental Lowering.
7. Adjustable support arms.
8.Safety valve against the breaking of the hydraulic circuit.
3. Warranty term:
Our products are warranted for one years on equipment structure, to be free of defects in material and workmanship.
Motors, gear box, power units, hydraulic cylinders, and all other assembly components such asturnplates, slip plates,Cables, chains, valves, switches etc, are warranted for one year against defects in material or workmanship under normal use.
I will provide to you best of serve and after sale serve.
4. More Images of Car Lift:
our other car lifts for sale:
