Home > Products > Kraft /corrugated paper machine > corrugated box machinery import from china 1575mm craft paper making machine
corrugated box machinery import from china 1575mm craft paper making machine
- 10 Set / Sets per Month
- qingdao or other ports
- T/T L/C
- 1760mm Foudrinier Wire Kraft/Corrugated Paper Machine,kraft wrapping paper mill for sale
- 1575mm 5-8t/d Double-dryer and double-mold corrugated paper machine
- 1880mm double-dryer can and double-cylinder mould corrugated paper machine
- 1760mm Multi-Dryer and Foudrinier Wire Kraft/Corrugated Paper Machine
- 1092mm 5t/d corrugated paper making machine,corrugating machine,paper bags raw material
- Corrugated sheet making machine
Product Details
Condition: | New | Type: | Other, paper making machine | Place of Origin: | Henan, China |
Brand Name: | jinhua | Model Number: | 1575 | Certification: | ISO |
Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
wooden package
Product Description
1575mm Double-cylinder and double-dryer paper machine
Technical data | |
Raw material | All kinds of waste paper(waste carton). |
Output paper | Paper board, kraft board. |
Net width | 1575mm |
Wire width | 1950mm |
Capacity | 10-15T/D |
Speed | 80-120m/min |
Rail gauge | 2400mm |
Drive way | AC converter, adjustable speed .Processing transmission |
Main frame of the equipment
Part name | Equipment | Specification | Quantity |
Mesh cylinder Part
| cylinder mould (stainless steel) | 1250×1950mm | 2 |
couch press | 400mm×1950mm | 2 | |
reverse press | 400mm×1950mm | 1 | |
Shore hardness | 38o±2 | ||
Press part | stone roll | 500×1950mm | 1 |
rubber roll | 450×1950mm | 1 | |
Shore hardness is 90o±2, pneumatic loaded equipment . | |||
Dryer part | dryer can | 2500mm×1950mm | 2 |
touch roll | 450mm×1950mm | 1 | |
riding roll | 400mm×1950mm | 1 | |
Pneumatic loaded equipment, and the second dryer is equipped with dry wire | |||
Winger roll | casting iron roll | 260mm×1950mm | 1 |
top rubber roll | 1 | ||
Mechanical pressure equipment | |||
Felt roll | felt roll | 159mm×1950mm | 28 |
If you provide the raw material, you will get various kinds of papers. The raw material is range from straw pulp, recycled paper; wood, to bamboo, bagasse. So you can also make good use of resources, getting good benefits from it.
All the equipments are packed with wooden boxes and straw.
- Pre-sales Service
- Offering comprehensive technical and business consultation services;
- Proposing the most suitable scheme and equipment for our clients;
- Designing and fabricating targeted products according to the special requirements of clients;
- Training periodically high qualified service technician.
2. After-sales Service
- Highly inspecting equipments in every working procedure, quality comes first;
- Fast & Safe Delivery; multi-cylinder
- Assisting our clients for foundation construction of equipments;
- Dispatching engineers to install and debug equipments;
- Training the first-line operators on site;
- Regularly visit clients to solve production problems;
- Providing life-long maintenance service;
Company Profile
Gongyi Jinhua Machinery Manufacturing Co., Ltd. is a joint venture which mainly produces complete equipment of equipment of pulping and paper machine complete equipment,waste recycling plant,shredder machine,crusher machine,agricultural drying machine .
Our company is located in China's transportation hub in Zhengzhou city, founded in 1980. The production facility covers an area of 8,600 square meters with a construction area of 20,800 square meters. With the management idea of sincerity, after thirty years of continuous development and strength, now we employ over 500 full time staff members with more than 100 professional technicians. We also employ 50 staff members who are translators, salespersons, electronic commerce persons. Our company is an integrated industrial enterprise of scientific research, product development, manufacturing and sale.
Our company has modern management systems, advanced manufacturing technology, complete testing methods, a large number of excellent processing equipment and high-quality skilled workers. All products pass ISO9001:2008 international quality authentication. Our products are sold throughout the world, including Canada,America,South America,Gremany,France,England, Southeast Asia, Bangladesh, Indonesia, Pakistan, Egypt, Syria, Mexico, Nigeria, Russia, etc. Our company wins customers' trust and recognition widely with integrity, pragmatism, refinement development and eternal commitment.
Our company offers an exceptional service team of sale and technology, who offers program and craft process design, technical training and so on. We also offer service of pre-sales, in-sales and after-sales.
