Oil Drill Crown Block TC Series For Drilling Rig
- 2000 Unit / Units per Month
- qingdao
- T/T Credit Card PayPal
You May Like
-
High Quality Crownblock Used On Oil And Gas Well Drilling Rigs
-
Hot sale!!! oil well drilling Hook
-
Latest High Quality Drilling Rig Hook
-
Oil Drilling Rig API 8C Traveling Block
-
API Standard Spec 8C Traveling Blocks Made In China
-
2016 API Traveling Block and Hook used on oil and gas well drilling rigs
Product Details
| Place of Origin | Henan, China | Brand Name | HF | |
| Model Number | Customized | Type | Other, Crownblock | |
| Machine Type | Drilling Tool | Certification | Other, CE , ISO | |
| Material | Other, customized | Processing Type | Other, customized | |
| Use | Other, oil drilling rig |
Product Description
Oil Drill Crown Block TC Series For Drilling Rig
Feature
In accordance with the standard of API 4F&8C.
The sheave rope groove through quenched proccessing with wear resistance, long-life.
Equipped with bump-proof cushion devices.
The traveling sheaves of the crown and its auxiliaries can be replaceable.
Ambient temperature:-20°C~55°C
-45°C~40°C
Technical Parameters
Model No.
| TC90 | TC135 | TC160 | TC180 | TC225 | TC315 | TC450 | TC675 |
| The max.hook load(KN) | 900 | 1350 | 1580 | 1800 | 2250 | 3150 | 4500 | 6750 |
| O.D of sheaves mm(in) | 605 (23 10/13) | 735 (28 12/13) | 760 (30) | 915 (36) | 915 (36) | 1270 (50) | 1524 (60) | 1524 (60) |
Number of sheaves
| 5 | 5 | 5 | 4+3 | 6 | 7 | 7 | 8 |
| Dia. of wireline mm(in) | 26 (1) | 26 (1) | 29 (1 1/8) | 32 (1 1/4) | 32 (1 1/4) | 35 (1 3/8) | 38 (1 1/2) | 38 (1 1/2) |
Overall Dim.mm (Length*Width*Hight)
| 1945 (76 7/13) | 1854 (73) | 2361 (92 12/13) | 2500 (98 15/64) | 2370 (93 4/13) | 4370 (170 1/2) | 3300 (130) | 3928 (154 5/8) |
1368 (53 55/64) | 1575 (62) | 1448 (57) | 1938 (65 7/13) | 1832 (72 3/26) | 3710 (111 1/2) | 2902 (114 1/4) | 3080 (121 1/4) | |
1691 (66 7/13) | 1586 (62 6/13) | 1544 (60 10/13) | 1684 (59 4/13) | 2286 (90) | 3555 (166 7/8) | 3760 (148) | 2915 (114 3/4) | |
Weight (kg) | 825 | 1114 | 1705 | 2095 | 3528 | 7945 | 10625 | 15340 |
O.D. of fast sheave.mm | 760 | 875 | 915 | 915 | 1070 | 1270 | 1524 | 1524 |
