Wheeled type 360-degree rotation Energy-saving drilling machine,11m depth pile drilling rig, HF360 piling drilling rig
- 30 Set / Sets per Month
You May Like
-
HF168 rotary piling machine 38 tons large torque for sale high quality with ISO & CE certification long lifespan
-
HF856A efficiency rotary drilling rig rotary
-
HF856A rotary drilling rig rotary drilling machine for piling foundation piling rig
-
HF525 small rotary drilling rig for sale used in piling foundation piling rig
-
HF856A rotary drilling rig rotary drilling machine for piling foundation piling rig
-
HF856A rotary drilling rig rotary drilling machine for piling foundation piling rig
Product Details
| Condition | New | Type | Other, auger drilling machine | |
| Power Type | Diesel | Brand Name | Hanfa | |
| Model Number | HF-360 | Usage | Other | |
| Dimension(L*W*H) | 7.5M*2.7M*2.6M | Weight | 8.6T |
Product Description
Specifications
Wheeled type360-degree rotation drilling machine,11m depth pile drilling rig, HF360 piling drilling rigSpecifications 11m dep
Wheeled type 360-degree rotation Energy-saving drilling machine ,11m depth pile drilling rig, HF360 piling drilling rig
Specifications
11m depth pile drilling rig, HF360 pilling drilling rig, sprial drill rod type
1. Spiral rod diameter 600mm
2. Depth 11m
Main Technical Parameter
HF-360 drill rig can drill up 11m when the diameter is 600mm, spiral drill rod with high effeciency working. Trailer type, easy installation and operating.
Model | HF-360 | ||
Hole diameter | 600mm | ||
Drilling depth | 11m | ||
Revolution angle° | 360° | ||
Overall dimension | Upright tube Max highest | 7500mm | |
Upright tube max width | 2700mm | ||
Wheel base | 4240mm | ||
track | 1420mm | ||
Max length | 7300mm | ||
Transport size | 6.5mX2.1mX2.6m | ||
Weight | 7.2t 8.6t | ||
Wheel | 6pcs | ||
Generator power | 50kw | ||
Hoist power | 2t/11kw | ||
Hydraulic oil pump power | 7.5kw | ||
Power machine | 6/22 KW | ||
Travel power | 34kw | ||
Oil pump flow | 32ml/r | ||
Oil pump pressure | 16mpa | ||
Power source | Generator set working and 380V external power working | ||
Travel type | Short distance travel by electric and hydraulic; long distance by diesel | ||
