Home > Products > Mini electric hoist > construction lift-- mini electric hoist /crane
construction lift-- mini electric hoist /crane
- 1000 Unit / Units per Month
- QINGDAO
- T/T Credit Card
Product Details
| Condition: | New | Place of Origin: | Shandong, China | Brand Name: | JNDO |
| Model Number: | PA | Usage: | Construction Hoist | Power Source: | Electric |
| Sling Type: | Wire Rope | Maximum Lifting Weight: | 1T | Maximum Lifting Height: | 10M |
| Lift Speed: | 5 / 10 M /MIN | Certification: | ISO,CE | Warranty: | 1 YEAR |
| After-sales Service Provided: | No overseas service provided |
Product Description
construction lift-- mini electric hoist /crane
PA mini electric hoist we sell is in compliance with the national standard. The design of mini electric hoist is reasonable with anvanced structure, beacutiful appearance, compact size size is compact and big tenacity, all of which make mini electric hoist safe and durable.Therefore the mini electric hoist enjoys a high reputation at home and abroad.
***Features of PA Electric Wire Rope Hoist
1. Excellent control characteristics, minimal setting force required, designed for one-handed operation.
2. Drop-forged, heat-treated suspension hook and load hook mounted on swivel steel balls with safety latches.
3. Motor insulation is B, magnetic single-phase. Double hook use, single hook use
4. Caged roller bearings on drum center shaft
5. Mini electric hoist speed can reach 10 m / min, the initial design rope length is 12 meters (longer can be customized), the hook specially designed with advanced settings, greatly increases the lifting weight of the mini electric hoist.
6. Simple structure, easy installation, small size, and single-phase power as a power source.
7. It can be applied in all kinds of locations in industry, business, handicraft industry and service industry not only on the overhead rails, but also be used in conjunction with many types of electric or manual cranes such as the single-girder crane, the double-girder crane, the cantilever crane and the gantry crane.
***Parameters of PA Electric Wire Rope Hoist
| Model | Method of Use | Rated Volt (V) | Input Power (W) | Rated Capacity (KG) | Lifting Speed (m) | Lifting Height (m) | Qty/CTN PCS | Packing Size(mm) | G.W/N.W (KG) |
| PA200M | Single-Hook | AC 220/230V 50/60Hz | 480 | 100 | 10 | 12 | 2 | 38×32×25 | 22.5/22 |
| Double-Hook | 200 | 5 | 6 | ||||||
| PA250M | Single-Hook | 510 | 125 | 10 | 12 | 23/22 | |||
| Double-Hook | 250 | 5 | 6 | ||||||
| PA300M | Single-Hook | 600 | 150 | 10 | 12 | 23.5/23 | |||
| Double-Hook | 300 | 5 | 6 | ||||||
| PA400M | Single-Hook | 950 | 200 | 10 | 12 | 45×34×27 | 33/32 | ||
| Double-Hook | 400 | 5 | 6 | ||||||
| PA500M | Single-Hook | 1020 | 250 | 10 | 12 | 33.5/32.5 | |||
| Double-Hook | 500 | 5 | 6 | ||||||
| PA600M | Single-Hook | 1200 | 300 | 10 | 12 | 35/34 | |||
| Double-Hook | 600 | 5 | 6 | ||||||
| PA800M | Single-Hook | 1300 | 400 | 8 | 12 | 38/37 | |||
| Double-Hook | 800 | 4 | 6 | ||||||
| PA1000M | Single-Hook | 1600 | 500 | 8 | 12 | 1 | 54×25×32 | 32/31 | |
| Double-Hook | 1000 | 4 | 6 |
* Factory appearance
*Company teams
*Production workshop
*Canton Fair
Contact Us
- Shandong Jndo Hoisting Equipment Co., Ltd.
- Contact nameDaisy su Chat Now
- Phone86-536-8262021
- AddressWest End Of Taixiang Street, Weicheng District Weifang,Shandong
-
