Electromagnet Lifting Magnet for Forklift

Name: Electromagnet Lifting Magnet for Forklift
Brand: JNDO
SKU: 141618844
Availability: InStock

Shandong Jndo Hoisting Equipment Co., Ltd.

US$ 1,960 - 1,960 MOQ: 1 Piece

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

JNDO

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name JNDO

Model Number MW5

Certification ISO,CE

Warranty 1 YEAR

After-sales Service Provided No overseas service provided

electromagnet lifting magnet for forklift

Product Description

*** Features of magnetic scrap lifter

1.The protection plate for coil adopts abrasion-resisting and shockproof rolling high-manganese steel.

2.The electromagnet is dealt with special technology, thus insulation grade can be up to Grade F.

3.Coils of magnets are made of Aluminum (flat aluminum wire covered by double spun glass) or cooper.

4.High lifting capacity, light self-weight.

5. Low power consumption, long service life.

*** Types of magnetic scrap lifter

1. Normal temperature type (DC-220V TD-60%)

2. High frequency type (DC-220V TD-75%)

3. High temperature type (DC-220V TD-60)

*** Parameters of magnetic plate lifter

Model			MW5-110L/1-75	MW5-130L/1-75	MW5-150L/1-75	MW5-165L/1-75	MW5-180L/1-75	MW5-210L/1-75	MW5-240L/1-75	MW5-250L/1-75
Overall dimension (mm)		A	1100	1300	1500	1650	1800	2100	2400	2500
		B	1270	1290	1360	1690	1650	1900	2100	2260
		C	220	250	350	370	370	400	450	450
		D	150	175	210	230	230	250	280	280
		E	45	50	60	75	75	80	90	90
Weight (kg)			1500	2280	3175	3840	4690	7810	10115	11100
Constant voltage control mode	Current in cold state (A)		27.6	40.7	51.4	55.6	73.9	98.5	117.6	185
	Consumption power in cold state (KW)		6.07	8.95	11.3	12.2	16.3	21.7	25.9	40.3
	Lifting capacity for impact ball (kg)		6500	8500	11000	12500	14500	21000	---	---
	Lifting capacity for packed pig irons (kg)		1000/800	1400/1100	1900/1500	2300/1800	2750/2100	3500/2800	4800/3800	5600/4500
	Lifting capacity for packed steel cuttings (kg)		450/400	700/600	1100/900	1300/1100	1600/1350	2200/1850	2850/2250	3500/2650
Strong excitation mode	Current in cold/hot state (A)		36.4/16.2	53.7/23.9	69.8/30.1	73.3/50.6	97.4/54	129.8/57.8	155/67.2	244/126
	Consumption power in cold/hot state (KW)		10.6/3.24	15.6/4.8	19.7/6.02	21.3/10.1	28.2/10.8	37.6/11.6	45/13.4	70.8/27.7
	Lifting capacity for packed pig irons (kg)		1050/900	1500/1250	2000/1700	2500/2100	2900/2400	3700/3100	5000/4200	6000/4850
