Super White Limestone Powder Sieve Machine, Gaofu Good Sales Separator, Linear Vibrating Sorting Machine

Xinxiang Gaofu Machinery Co., Ltd. Gold Verified Supplier
5Yrs
Super White Limestone Powder Sieve Machine, Gaofu Good Sales Separator, Linear Vibrating Sorting Machine thumbnail-1
Super White Limestone Powder Sieve Machine, Gaofu Good Sales Separator, Linear Vibrating Sorting Machine photo-1
US$ 2,000 - 6,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New, new
Type:
Linear
Application:
Ore
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin or other
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Linear
Application Ore
Place of Origin Henan, China
Brand Name Gaofu
Model Number SZF-1235-2S
Voltage 220V.380.415V or others
Power(W) 2*2.2KW
Dimension(L*W*H) 1450*3800*1600MM
Weight 2200Kg
Certification CE, ISO9001:2008, BV, SGS
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

                                                  super white limestone powder sieve machine



1. SZF Series powder sieve machine is low consuming, high output, simple structure, easy,maintain, no powder dispersed, automobile discharged.

It can be used universally for test screening or to produce between 2 and 4 screen fractions.

A good screening effect is achieved by the circular vibration in the vertical plane.





 2. SZF Series powder sieve machines are very useful in limestone, plastics, rubber, ceramic, chemical, fertilizer, glass industries, food, pharmaceutical.

Vibratory screens can be provided with dust proof cover as required.

SZF Series linear powder sieve machine can be supplied of different sizes depending upon capacity required. They can also handle slightly wet material.



   Make the order: Inlets, outlets and legs can be custom fit to your installation requirements.



3. Technical Parameters



Model

Size(mm)

Material size(mm)

Inclination

Amplitude(mm)

Layer

Power(KW)

SZF-520

500×2000

      0.074-10

0-7 degree

 4-10

 1-6 layer

2*(0.4-0.75)

SZF-525

500×2500

2*(0.4-0.75)

SZF-1020

1000×2000

2*(0.4-0.75)

SZF-1025

1000×2500

2*(0.4-1.1)

SZF-1030

1000×3000

2*(1.1-1.5)

SZF-1040

1000×4000

2*(1.1-1.5)

SZF-1235

1000×3500

2*(1.1-2.2)

SZF-1250

1200×5000

2*(1.1-2.2)

SZF-1535

1500×3500

2*(1.1-2.2)

SZF-1560

1500×6000

2*(2.2-3.7)

SZF-1845

1800×4500

2*(2.2-3.7)

SZF-2050

2000×5000



0.074-15

2*(2.2-3.7)

SZF-2260

2200×6000

2*(2.2-3.7)





4. Details of the machine(Quick clamp hand)





super white limestone powder sieve machine, Gaofu good sales separator, linear vibrating sorting machine







Package

super white limestone powder sieve machine, Gaofu good sales separator, linear vibrating sorting machine



== used in production field ==

super white limestone powder sieve machine, Gaofu good sales separator, linear vibrating sorting machine
