Home > Products > Lime Slaking Machines > Rotary Drum Lime Slaker to Produce Good Quality Lime Milk

Rotary Drum Lime Slaker to Produce Good Quality Lime Milk

FOB Price

USD $8,600 - $150,000 / Set

1 Set(Min.Order)

Supply Ability 35 Set / Sets per Month
Port QINGDAO
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Product Type	Other, lime slaking machine	Place of Origin	Henan, China
Brand Name	DINGLI	Model Number	XH1500
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Rotary Drum Lime Slaker

Application of lime slaker:

Lime slaker is also called lime slaking machine, lime milk machine, used for slaking of calcium carbonate, calcium hydrogen phosphate lime, mainly used in chemical industry, chemical fiber, paper making, power plant desulfurization, sugar, biology pharmacy, soda ash manufacturing and other industries. The lime slaker produced by our company is divided into the front type and rear type lime slakers two series.

Structure of lime slaker:

Lime slaker is mainly composed of outer cylinder, inner cylinder, supporting device and transmission device, of which the tail has in dregs removing device. The lime slaking machine main characteristic is to use the rotary motion instead of mixing method of slaking. There are screen holes at the back end of the inside cylinder, where lime lumps and water are contacted and slaked. The lime milk flows through the screen holes to the feeding direction and discharged at the bottom outlet. The lime which are not able to be slaked are discharged from the dregs removing device at the tail of outer cylinder. The slaker machine structure device is of reasonable design, convenient operation, high production efficiency, large production capacity, small labor intensity and are applicable to all the quality of lime.

Features of lime slaker:

1. Lime milk quality is good and exquisite, with high production of pulp, and the concentration of lime milk can be adjusted conveniently, by increasing and reducing of feeding amount to control lime milk concentration control.

2. Fast slaking and high efficiency. Due to taking full advantage of the lime slaking exothermic, remain the state of boiling in the slaker material, losing small heat, very fast slaking in 15 minutes fully slaked to the high digestion temperature.

3. Good operating environment, realized the mechanization production, slag removal is convenient, the use of lime slaker machine at the back of the installation of the dregs removing machine, 95% of the ash in the lime emulsion can be separated.

4. High mechanization degree, easy operation, digestion, slag fully realized mechanization, there is no need of personnel in the normal production process operation, low labor intensity.

5. Sealed ends by the special design, can guarantee no leakage, implements the production site clean.

6. Optional PLC control system, PLC through analog signals (4-20 ma) by the frequency converter control feed rate and the main engine rate of revolution, realizing automation production, the vector control system of type inverter can through self-learning or artificial set low frequency torque compensation, realize the big moment of low frequency of digestive machine start, greatly improves the digestion machine startup performance. Control system of dust, moisture proof processing, make it more applicable to the dusty and humid environment.

7. The lime slaker does not produce harmful waste gas in the process of digestion, the emissions of gases contain a small amount of water vapor of calcium hydroxide, such as the need to eliminate, can be equipped with dust removal device for dust removal process.

Technical Specification of lime slaker:

Model	XH-800	XH-1000	XH-1300	XH-1500	XH-1800	XH-2000
Lime milk capacity(m3/h)	4-8	10-15	10-22	22-28	28-40	40-60
Lime milk density(0 Be°)	13-15	13-15	13-15	13-15	13-15	13-15
Drum rotating speed(rpm)	3-7	3-6	3-5	3-5	3-5	3-5
Drum innersize(mm)	800	1000	1300	1500	1800	2000
Drum length(mm)	8000	10000	12000	14000	16000	18000
Efficient volume index(%)	20	20	20	30	30	40
Motor power(kw)	4	5.5	7.5	11	15	15
Total weight(Kg)	6500	7800	13800	18500	24500	29600
