QINGZHUAN Low Bed Semi Trailer 40T Tractor Trailer (manufacturer)

Name: QINGZHUAN Low Bed Semi Trailer 40T Tractor Trailer (manufacturer)
Brand: sinotruk
SKU: 141665906
Availability: InStock

SINOTRUK Qingdao Heavy Industry Co., Ltd.

US$ 10,000 - 50,000 MOQ: 1 Unit

Key Specifications

Type:

Semi-Trailer

Material:

Steel

Certification:

Other, ccc

Payment & Shipping

Payment Methods:

Port of Shipment:

CHINA MAIN PORT

Delivery Detail:

Delivery time depends on order quantity.

Type Semi-Trailer

Material Steel

Certification Other, ccc

Size 13000x3000x2950mm

Max Payload 40000

Place of Origin Shandong, China

Brand Name sinotruk

Specifications

Adopt international standards to design and manufacture, solid and durable, safe and reliable;Semi Trailer

Specification:
	Axle number	two
	Axle specs.	FUWA Brand
	Suspension	Common mechanical Suspension(America type)
	Wheel	12.00R20
	King Pin	JOST 3.5” traction pin
	Dimensions (LxWxH)	1300030002950mm
	Support legs	JOST D200T
	Rim	8.5-20
	Steel Spring	10/10/10pieces per axles (Intensify)

Tire:
	Number of Tire	8 pieces
	Spare Tire Carriers	2 pieces
Frame:(specs. and materials)
	The material of Main beam	The height of the beam is500mm,upper plate is 20 mm, down plate is20 mm, middle plate is 12mm,Made of Q345.Side beam is25# Channel Steel, made of Q235.
	Platform plate	5mmDiamond Plate
	Rear Steel Ladder	Two pieces
Brake:
	Emergency Brake Valve	WABCO
	Brake Chamber	Two double and two single chamber( TKL brand )
	ABS system	without
Electrical:
	Voltage	24V
	Receptacle	7 ways(7 wire harness)
