Specifications
heavy truck semi trailer1.Q345 steel beam chassis
2.WMI BV CCC ISO
3.Direct manufacturer
4.MOQ:1 SET
heavy truck semi trailer
| King pin location | ne position on 500mm from the front face of the front bolster |
| Fifth wheel height | 1340mm with the chassis level |
| Landing gear location | 2150mm behind the king pin |
| Tare weight (Tolerance 0-4%) | approximate 8200kg |
| Payload | 65000kg |
King Pin | φ50mm |
| Landing Gear | 2 speed road side winding with sand shoe, Lifting capacity 24T. |
| Suspension | Mechanical suspension with 10 leaf spring (90mm width by 16mm thickness/leaf) |
| Axles | Fuwa square axle with 15tons capacity |
| Rims | 8.0-20 disc wheel, 13PCS; Supplier:Sunrise |
| Tires | 11R22.5 tyre/18, 13PCS; Supplier: Triangle |
| Brake System | Non ABS brake system |
| Brake Chamber | 30/30 type |
| Electric system | 24 volt lighting system with modular wiring harness, 7-pin socket |
| Surface | Sand blast before coating Zinc-rich premier & top coating |
| Color | White |
