Home > Products > Dredger equipment > Floating Dredge Pipe
Floating Dredge Pipe
- 5000 Meter / Meters per Month
- Qingdao
- T/T
Product Details
| Place of Origin: | Shandong, China | Brand Name: | Xianke | Model Number: | XKP-550 |
| Condition: | New | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
HDPE DREDGING PIPE
High-density polyethylene(HDPE) pipe is made from high density polyethylene as the main
raw material, adding a small amount of antioxidants, Anti-UV absorbers and pigments
and be extruded by once-shaping technology from a plastic extruder.
Used for Sand Suction Dredger
Application Field of HDPE Pipe
1. Water supply ;
2. Sand, mud, ore,slurry dredging and discharging project;
3. Industrial raw material transmission pipeline;
4. Agricultural irrigation pipeline.
5. Other application.
Fetures of HDPE pipe
1. Non-toxic and healthy: no heavy metal additives, would not be covered with dirt or
contaminated by bacterium.
2. Anti-corrosion: resist variety of chemical mediator except few oxidants.
3. No leakage: good connection types.
4. Small flow resistance: smooth interior walls result in lower pressure loss and higher volume
than metal pipe.
5. Good flexibility: PE pipe can be coiled in longer length.
6. Long life-span: more than 50 years under normal condition
Technical Specification
PE100 Grade HDPE Pipe | |||||
O.D.(mm) | Standard Dimensions | ||||
SDR26 | SDR21 | SDR17 | SDR13.6 | SDR11 | |
Normal Pressure(Mpa) | |||||
0.6 | 0.8 | 1 | 1.25 | 1.6 | |
e(mm) | e(mm) | e(mm) | e(mm) | e(mm) | |
20 | |||||
25 | 2.3 | ||||
32 | 3 | ||||
40 | 3.7 | ||||
50 | 4.6 | ||||
63 | 4.7 | 5.8 | |||
75 | 4.5 | 5.6 | 6.8 | ||
90 | 4.3 | 5.4 | 6.7 | 10 | |
110 | 5.3 | 6.6 | 8.1 | 10 | |
125 | 6 | 7.4 | 9.2 | 11.4 | |
140 | 4.3 | 6.7 | 8.3 | 10.3 | 12.7 |
160 | 4.9 | 7.7 | 9.5 | 11.8 | 14.6 |
180 | 5.5 | 8.6 | 10.7 | 13.3 | 16.4 |
200 | 6.2 | 9.6 | 11.9 | 14.7 | 18.2 |
225 | 6.9 | 10.8 | 13.4 | 16.6 | 20.5 |
250 | 7.7 | 11.9 | 14.8 | 18.4 | 22.7 |
280 | 8.6 | 13.4 | 16.6 | 20.6 | 25.4 |
315 | 9.7 | 15 | 18.7 | 23.2 | 28.6 |
355 | 10.9 | 16.9 | 21.1 | 26.1 | 32.3 |
400 | 12.3 | 19.1 | 23.7 | 29.4 | 36.3 |
450 | 13.8 | 21.5 | 26.7 | 33.1 | 40.9 |
500 | 15.3 | 23.9 | 29.7 | 36.8 | 45.4 |
560 | 17.2 | 26.7 | 33.2 | 41.2 | 50.8 |
630 | 19.3 | 30 | 37.4 | 46.3 | 57.2 |
