quartz halogen oven heating element,timber dryer infrared heating lamp
- 10000 Piece / Pieces per Month
- Shanghai
- T/T
You May Like
-
timber drying lamp quartz tube heating element
-
High power low color temp carbon fiber IR lamp infrared heater element
-
2016 new 2500K carbon fiber IR lamp quartz heater element
-
Carbon Medium Wave IR heat lamp quartz heater element
-
Wood drying short wave quartz element infrared heater tube 6000W
-
Wood drying oven carbon medium wave quartz heater tube 2000W
Product Details
| Place of Origin | Anhui, China | Brand Name | Quickly | |
| Application | heating and drying, widely used in all kinds of industry heating process | Surface Treatment | Gold Coated | |
| Outside Diameter | 10,12,15,23*11,33*15mm | |||
Product Description
Application: Timber Drying
Product | Short wave IR heat lamp | Medium wave IR heat amp | |
Wave length | 1.0-1.4μm | 2.4-2.7μm | |
Heating response time | 1 second | 1-4min | |
Voltage | 110v/230v/380v/400v,customized available | ||
Max. Length for twin tube | 6000mm | ||
Max. filament temp | 2200°C | 900°C | |
Watt density | 35-200w/cm | 10-30w/cm | |
Working expectation | 5000hours | 20000hours | |
Dia. of twin tube | 23×11mm / 33×15mm | ||
Wall thickness of tube | 0.8mm,1.0mm,1.2mm,1.5mm,1.8mm | ||
Dia. of single tube | Φ10mm, Φ11mm, Φ12mm, 15mm,18mm, 20mm | ||
Max. length for single tube | 1600mm(Φ12mm) | 2000mm(Φ15mm) | |
Main material | filament | tungsten filament | Ni80Cr20 heating wire |
| quartz glass | can resist high temperature, sudden hot and cold | |
Inner structure of quartz tube | Quartz envelope profile , vacuum processing with protective halogen gas inflation, which provide a safe working environment | Quartz envelope profile , Non-vacuum | |
Surface of quartz tube | 1. White reflector/Gold reflector: High heat radiation rate 2. Transparent tube: Normal style 3. Ruby tube for shortwave | ||
Market in
1.Delivery and Package
2.Payment Terms
3.Reply inquiry within 24hours
4.Customize size are welcome,OEM welcome. Sample order are welcome.
5.Every lamp will be tested by our QC department before shipping. Any damage
before delivery will be replaced right away. Damage caused by delivery
and no man-made reason within guarantee will also send the replacement heaters for you.
