Fire Resistance V2 Grade White Large Prism PC Diffuser/Light Diffusion Polycarbonate Sheet

Name: Fire Resistance V2 Grade White Large Prism PC Diffuser/Light Diffusion Polycarbonate Sheet
Brand: Lixin or OEM
Availability: InStock

FOB Price

USD $10 - $20 / Square Meter

800 Square Meters(Min.Order)

Supply Ability 10000 Ton / Tons per Month
Port Shanghai or Ningbo
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:

China

Brand Name:

Lixin or OEM

Model Number:

Light Diffusion Polycarbonate Sheet

Product Description

Fire Resistance V2 Grade White Large Prism PC Diffuser/Light Diffusion Polycarbonate Sheet

Product Description

Gensin prism polycarbonate sheet, the special optical prism design, makes the sheet even with clear color also can scatter the light. It is made from 100% Sabic or Bayer virgin material.The light transmittance is almost close to 90%. Compared with PMMA sheet, polycarbonate sheet is much higher impact strength, better fireproof.

Item	Prism size	Sheet Thickness	Standard Size
Prism PC sheet	5mm	3-10mm	1220*2440mm

Datasheet:

Item	Property	Value
Polycarbonate Solid Sheet	Light weight	Density:1.2Kgs/cbm, half weight of glass
	Light transmission	80%-90% for different thickness of clear color
	UV resistance	50μm UV layer, filter 99% ultraviolet radiation in sunlight
	Coefficient of thermal expansion	0.065 mm/m°c
	Service temperature	-40°c to 120°c
	Heat conductivity	2.3-3.9 W/m²℃
	Tensile strength	>60N/mm²
	Flexural strength	100N/mm²
	Tensile street at break	>65mPa
	Heat deflection temperature	140°c
	High Impact strength	impact strength is 250 times of glass, 20-30 times of PMMA sheet
	Fire Rating	B1/V2, self-extinguish within 60 seconds

Applicaton of prismatic polycarbonate sheet:

1.Advertising light boxes, signs, outdoor

billboards, LED lighting, Guides system, light cover

2.Indor windows and door

3.Indoor partition

4.Advertising panel

Product Display

5mm Prism: min thickness 3mm; Clear color/ Diffusion White; custom size
