carbon steel flange

FOB Price

USD $2 - $50 / Ton

1 Ton(Min.Order)

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Material:	Carbon Steel	Standard:	BS	Place of Origin:	Shandong, China
Model Number:	DN80	Brand Name:	xr	Standard or Nonstandard:	Standard

1.we supplyflange
2.OD:1"~20", Thk:3mm~50mm
3.quality: ISO 9001:2000
:middle east,southern America etc

Quick Details

Size: 1/2"-64"	Material: Stainless Steel	Standard: DIN
Place of Origin: Shandong China (Mainland)	Model Number: FL25	Brand Name: LFX
Standard or Nonstandard: Standard	class: pipe fittings

Packaging & Delivery

Packaging Detail:	pollywood pallets
Delivery Detail:	30days

Specifications

1.size:1/2"-64"
2.Materials:stainless steel or carbon steel
3.Standard:JIS,EN,DIN,ANSI,ASME
4.Type: slip on , blind , WN ,SW

--Method

by forging ,forged flange

--Pressure Rating

class 150 300 600 900 1500 2500

PN 6 PN10 PN16 PN25 PN40 PN64

JIS 5K 10K 16K and 20k

--Type:

plate , slip on , weld neck , blind , threaded , and special mode

--Painting

Rust preventative oil painting or back /yellow/ varnish painting or galvaizing

Item#	FL25
Name	steel din forged flange
Range	½” (15 NB) to 64” (1200NB) in 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS ASA 150,
	ASA 300, PN 6,10,16,25, 40,64,100,160 ETC. Available with NACE MR 01-75
material	stainless steel , carbon steel , nickel alloy ,cast iron ,brass , aluminum
standard	ANSI : ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, ANSI B16.48
	DIN : DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636, DIN2637, DIN2638, DIN2673
	B.S : BS4504 , BS4504, BS1560, BS10
	OTHER : PLATE, PLATE BLANK
package	pollywood pallets
payment terms	100% L/C or 30% advanced T/T . The balance before shipment
