Made in China sewage water pump with water pumps parts
USD $60 - $70
/ Set
5 Sets(Min.Order)
- 1400 Set / Sets per Month
- Chongqing
You May Like
-
Sewage Pump(3 Inches) with hydraulic pump water
-
Electric Power and Diesel,Oil,Water,Gasoline,Milk,Juice,Non-acid liquids Usage irrigation
-
Industry usage sewage pumps of hydraulic trash pump
-
3 inch sewage pump with centrifugal pump
-
Industry usage sewage pumps of gasoline engine power sprayer pump
-
JUANYONG brand 4 inch solid waste pump
Product Details
| Place of Origin | Chongqing, China | Brand Name | JUANYONG | |
| Model Number | WB100 | Theory | Centrifugal Pump | |
| Structure | Single-stage Pump | Usage | Water | |
| Power | Hydraulic | Standard or Nonstandard | Standard | |
| Fuel | Other, diesel&gasoline | Pressure | Low Pressure | |
| Application | Sewage |
Product Description
Product Series
| ITEM | WB100 |
| Outlet Size(mm) | 100 |
| Inlet Size(mm) | 100 |
| Speed(rpm) | 3600 |
| Displacemnet Q.max(m3/h) | 68 |
| Lift H.max(m) | 20 |
| Suction(m) | 5 |
| Engine Model | 190F |
Engine Crankshaft Data Request
Water Series
Installation Diagram&Part List
| Serial Number | Name | Number |
| 1 | Water pump cover | 1 |
2 | Aluminum flat washerΦ8×Φ16×1.5 | 4 |
| 3 | Bolt M8×30&45 GB5787 | 4 |
| 4 | Mechanical seal/ceramic | 1 |
| 5 | Impeller | 1 |
| 6 | Eddy shell sealing ring | 1 |
| 7 | Eddy shell | 1 |
| 8 | Inlet sealing gasket | 1 |
| 9 | Pump sealing ring | 1 |
| 10 | Water pump body | 1 |
| 11 | Rubber plug gasket | 2 |
| 12 | Threaded plug pump | 2 |
| 13 | Bolt | 6 |
| 14 | Pipe joint sealing gasket | 2 |
| 15 | pipe joint connecting nut | 2 |
| 16 | Pipe joint | 2 |
| 17 | clamp | 3 |
| 18 | The filtering orifices | 1 |
| 19 | Filter cover | 1 |
