VERTICAL axis wind turbine 1-5kw

Specifications

Wind turbine
-Noisy level < 40db
-Working wind 3-25m/s
-Maglev designed technology
-CE approved

WIND TURBINE



MAGLEV DESIGNED



Model:TECHMLV5kw





 5kw/3kw Maglev VAWTs references from our users abroad:



Vertical Axis Wind Turbine 1-5kw



LOOKING FOR DISTRIBUTORS...

Model:TECHMLV5kw/3kw 220v/360VDC system

220VDC /Off-grid Designed system

360VDC /On-grid Designed system





Our Advantages

---Magnetic Levitation designed generator

---Low  noise  below 40db, less noisy

---high efficiency,less vibration
---Lower  price, much popular designed style



System Kits

- Wind turbine + Blades Assembly

- Free-stand Mast (Hot galvanized 8m)

- Off-grid Controller + Battery + Inverter  + Loads







Model	TECHMLV 5kw
Rotor Diameter (m)	4.0
Material of blades and No.	RFP/ 5 pcs
Rotation per minute for generator  (rpm)	150 -170rpm
Working wind speed (m/s)	3-25
Cut-in wind speed (m/s)	3
Rated wind speed (m/s)	11
Survival wind speed (m/s)	50
Rated output power at rated wind speed (kw)	5kw
Maximum output power (kw)	7kw
Rated output voltage (V)	DC 380V/220V
Generator type	PMG 3 phs, AC output
Suggestion battery	12v 150ah 18 pcs
Warranty	2 years for Generator,1 year for spare parts













Our homepage:





About Us:



- We, Techwellpower is one of the leading supplier of residential maglev vertical  wind turbine from China with 10 years experience.

- Our wind turbines have been installed in around 50 countries with more than 50 stable international customers. Techwellpower is capable to put the wind work for you with lower cost.

- Our VAWT ranges from 500w - 5000w, in name of the model of TECH 300w -5kw, TECHMLV3kw/5kw, TECHVH2kw, both on-grid and off-grid system available.

- At techwellpower, we take pride in offering advanced products that let homewoners and business generate their clean power.

- Our VAWT is designed for harsh climate, they are built simply and ruggedly to quietly last.Our machines have a large wind swept area to capture more wind and produce more energy, especially in low wind . These machines produce energy in the wind you get, day in and day out, power when you need, not just in storms.

-Detailed information please contact us at  anytime.

- In the past 2011, we have installed more than 80pcs of Maglev wind turbine.



Welcome to Techwellpower !



The following is 5kw ON-grid Inverter/ Controller/Dump load for the generator:
