Home > Products > Construction and Mining machine > XY-200 hot sell cheap portable diamond drilling
XY-200 hot sell cheap portable diamond drilling
- 100 Set / Sets per Month
- Fuzhou or other port from China
- T/T Credit Card
Product Details
| Condition: | New | Type: | Other, Core Drilling Rig, water well drilling rig | Power Type: | Diesel |
| Place of Origin: | Fujian, China | Brand Name: | DSL | Model Number: | XY-200 |
| Usage: | Water Well | Voltage: | 100 | Power(W): | 5 |
| Dimension(L*W*H): | 10450*1030*1460 | Weight: | 975kg | Certification: | CE |
| Warranty: | 5years | After-sales Service Provided: | Overseas third-party support available |
Product Description
Specifications
water well drilling rig1.Similar to good brand
2.Well design below to factory,low price.
3.Drilling depth:200m
4.CE
XY-200 hot sell cheap portable diamond drilling
The application scope about the drilling rig
Used for general investigation, geophysical exploration, high-way and building construction, and blast-hole drilling etc.
- With hydro-automatic feeding device, and high drilling efficiency.
- Designed with hydro-chucking unit instead of slips to ensure drilling from stop when changing pipes.
- Close levers, convenient to operate, safe and reliable operations.
- Compact in structure. All the drill, water pump and diesel engine installed on one base frame result in space-saving.
- Light in weight, easy disassembling for transportation and applicable to working conditions in plain and mountain areas.
The specification of the drilling rig
Specifications | ||
Unity machine parameter | ||
Drilling depth | 100 180m | |
Drill rod caliber | 50 42mm | |
End hole caliber | 75 46mm | |
Maximum open hole caliber | 220mm | |
Drilling angle | 90°~75° | |
Unity machine dimensions | 2.1×0.9×1.3m | |
Drill weight (No include power) | 610kg | |
Spindle | ||
spindle speed | 130 300 480 730 830 1045r/min | |
Spindle stroke | 450mm | |
Hoist | ||
Max.single line hoisting capacity | 11KN | |
Single line lifting speed | 1.06 0.67 0.32m/s | |
Tightrope caliber | 9.3mm | |
Tightrope cubic measure | 35m | |
Hug floodgate belt width | 50mm | |
Hug floodgate caliber | 240mm | |
Mud pump | ||
Type | Horizontal single urn twin-action | |
Displacement | 95 77L/min | |
Diesle engine | s1105 18HP | |
Electric motor | Y160M—4 11KW | |
Maximum pressure | 1.2Mpa | |
Work pressure | 0.7Mpa | |
Some picture about the drilling rig
---------------------------------------------------------------------------
Mob: +86-15750862797
Skype:digswordland.mary
The specification of other drilling rig
Model | XY-100 | XY-130 | XY-180 | XY-200 |
|---|---|---|---|---|
Drilling depth | 100m | 130m | 180m | 200m |
Maximum open hole diameter | 200mm | 220mm | 220mm | 300mm |
End hole caliber | 75mm | 75mm | 75mm 46mm | 75mm |
Drill rod caliber | 50mm | 50mm | 50mm 42mm | 60mm |
Drilling angle | 90°~75° | 90°~75° | 90°~75° | 90°~75° |
Drill weight(No include power) | 480 510kg | 560kg | 610kg | 975kg |
