Rectangular Table surface grinding machine
- 50 Set / Sets per Month
- shanghai port
- T/T L/C D/P D/A
Product Details
Condition: | New | Type: | Surface Grinding Machine | CNC or Not: | CNC |
Max. Grinding Diameter: | 335 450 490 460 | Max. Grinding Length: | 550 520 540 520mm | Place of Origin: | Jiangsu, China |
Brand Name: | SMAC | Model Number: | SG-2050H/AH SG-2550AH SG-3063AH SG-30100AH SG-4080AH SG-40100AH SG-205 | Voltage: | 220V 380V |
Power(W): | 1.5 2.2 5.5 | Dimension(L*W*H): | 178 x 150 x 218 190 x 170 x 218 200 x 210 x 218 235 x 222 x 220 295 x | Weight: | 2600 2100 1800 1700 KG |
Certification: | CE ISO SGS | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Features:
-Automatic feed for 3 axis
Standard accessories:
Grinding wheel;
Wheel flange;
Wheel balancing base;
Wheel balancing arbor;
Extractor;
Diamond dresser;
Leveling pad;
Anchor bolt;
Tool box with tools
Optional accessories:
Permanent magnetic chuck;
Tiltable permanent chuck;
Electro-magnetic chuck;
Demagnetizer;
Overhead parallel dresser;
Angle dresser;
Radius dresser;
Chuck control;
Rapid elevation;
Micro feed;
Digital readout system;
Rear splash guard;
Suction device;
Cooling & suction device;
Magnetic separator;
Cooling c/w magnetic paper filter.
Description for model:
AHD: X axis hydraulic, Y axis motorized, rapid grinding head elevation, grinding head auto down feed.
13807-1 | 13806-1 | 13805-1 | 13805-2 | 13803-1 | 13803-2 | |||
DescrpitionModel | Unit | SG-2050H/AH | SG-2550AH | SG-3063AH | SG-30100AH | SG-4080AH | SG-40100AH | |
SG-2050AHR | SG-2550AHR | SG-3063AHR | SG-30100AHR | SG-4080AHR | SG-40100AHR | |||
SG-2050AHD | SG-2550AHD | SG-3063AHD | SG-30100AHD | SG-4080AHD | SG-40100AHD | |||
Table size (W x L) | mm | 200 x 460 | 250 x 500 | 305 x 635 | 305 x 1020 | 406 x 813 | 406 x 1020 | |
Table travel (X x Y) | mm | 510 x 238 | 560 x 275 | 765 x 340 | 1130 x 340 | 913 x 450 | 1130 x 45 | |
Max. distance from spindle center to table | mm | 450 | 450 | 580 | 580 | 580 | 580 | |
Magnetic chuck size | mm | 200 x 460 | 250 x 500 | 300 x 600 | 300 x 1000 | 400 x 800 | 400 x 1000 | |
Speed of table longitudinal movenment | m/min | 7-23 | ||||||
transverse movement | Auto feed | mm/min | 0.1-8 | |||||
Rapid speed | m/min | 990 | ||||||
Feed of handwheel | mm/div. | 0.02 | ||||||
Wheelhead vertical movement | Auto feed | mm | (AH/AHR model)/0.05/0.01/0.02/0.03/0.04/0.05(only AHD model) | |||||
Rapid speed | mm/min | (AH model)/460(AHE/AHD model) | ||||||
Feed of handwheel | mm/div. | 0.05 | ||||||
Grindng wheel | Speed | rpm | 2850 (50Hz) 3450(60Hz) | 1450 (50Hz) 1750(60Hz) | ||||
size (OD x W x ID) | mm | 200 x 20 x 31.75 | 350 x 40 x 127 | |||||
Spindle motor | kw | 1.5 | 2.2 | 5.5 | ||||
Hydranlic motor | kw | 0.75 | 2.2 | |||||
Cooling pump motor | kw | 0.04 | 0.125 | |||||
Elevating motor | kw | (AH/AHR model)/0.25 (AHR model)/0.05(AHD model, servo motor) | ||||||
Cross feed motor | kw | 0.04 | ||||||
Max. loading capacity of table (include chuck) | kg | 120 | 180 | 270 | 400 | 500 | 600 | |
Total rated power | kw | 3 | 3.7 | 9 | ||||
Height of machine | mm | 1675 | 1890 | |||||
Floor space (L x W) | mm | 2050 x1400 | 2250 x 1650 | 2800 x 2200 | 4400 x 2200 | 3400 x 2400 | 4400 x 2400 | |
Gross weight | kg | 1600 | 1800 | 2800 | 3500 | 3800 | 4300 | |
Package dimensions (L x W x H) | cm | 178 x 150 x 218 190 x 170 x 218 | 200 x 210 x 218 | 235 x 222 x 220 | 295 x 222 x 220 | 285 x 227 x 220 | 295 x 227 x 22 |
All of our goods will pass QUALITY INSPECTIONS before shipment.
Best after sale service, customer can follow their order situation any time, no matter on product line, warehouse or shipment.
More than 10 years experience in exporting to make your order more smooth.Less than one container loading is accepted.
On time delivery, in general 30 days. Multimode payment:T/T,L/C.
Special dimensions available according to request.
We have many certificates of our Products.
Accessories replacement if our product itself has quality problems during one year after receiving.
Found in 1984 Our SMAC/Jmech Machine Tool Co., Ltd as the main partner member of China Jiangsu International Economic-Technical Cooperation Corporation. specializes in import& export of brand-new industrial machinery & tools. Our mechanical products cover more than 80 kinds including lathe, milling machine, grinding machine, power press, hydraulic guillotine, hydraulicpress brake, CNC & automotive machines and so on, which have been exported to 40 or more countries & areas.
SMAC/Jmech Machine Tool Co., Ltd is proud to be the professional, high reputation company with high-qualified & professional staff, competitive prices and quick & thoughtful after-sale service to cooperate with you.
