1. Unlimited clockwise and anti-clockwise 360 degree rotatable. Special designed swing bearing for durability and big cylinder for more power
2. Check valve is embedded for better safety shock value enclosed for better safety from damage
3. Wear resistant special solid steel is used and no extra reinforcement is requirement.
4. The wide opening width with light weight, not only outstanding performance handling the iron bar but also maximize his operation efficiency with light weight.
5. Minimized hydraulic trouble which may occur during rotating works.
Quality is guaranteed | Faster | Safer |
1.12 month after-sales warranty 2. We have the profession team (Pre-sale service, Technical team, After-sales service.) and will solve all your problems. 3.13 years working experience in this filed. | We are near Shanghai Port, Ningbo Port.Our hot-sales pruducts will be deliveied within 7days. |
|
1. Make sure of the weight of your carrier.
2. Make sure of the oil flow of your excavator.
3. Make sure of the wood or stone which you want to carry.
Model | unit | RHG03 | RHG04 | RHG06 | RHG08 | RHG10 | RHG14 | RHG20 |
Weight | Kg | 240 | 390 | 740 | 1380 | 1700 | 1900 | 2100 |
Jaw opening | mm | 1300 | 1400 | 1800 | 2300 | 2500 | 2500 | 2700 |
Working pressure | Kg/cm² | 110-140 | 120-160 | 150-170 | 160-180 | 160-180 | 180-200 | 180-200 |
Setting pressure | Kg/cm² | 170 | 180 | 190 | 200 | 210 | 250 | 250 |
Oil flow | l/m | 30-55 | 50-100 | 90-110 | 100-140 | 130-170 | 200-250 | 250-320 |
Cylinder | ton | 4.0 x 2 | 4.5 x 2 | 8.0 x 2 | 9.7 x 2 | 12 x 2 | 12 x 2 | 14 x 2 |
Carrier | ton | 4 - 6 | 7 - 11 | 12-16 | 17-23 | 24-30 | 31 -40 | 41-50 |
