all types of Layher system scaffolding,cuplock and frame scaffolding

BY STEEL PALLE

Specifications

Layher system scaffolding
1) Raw materil:Q235&Q345
2)Surface finish:painted .HDG
3)Pipe:48.3*3.2mm/3.8mm
4)Standard.Ledger

Ringlock scaffolding Component/  Layher system scaffolding /layher scaffolding system.all round system



Standard

Use: Standards are the vertical members of ringlock scaffolding. They provide the

vertical support for scaffolding.



ledger

Use: Ledgers are the horizontal members of Ringlock scaffolding. They provide

horizontal support for loads and planks. Ledgers can also be used as mid rail and top or hand guard rails



Base collar

Use: The base collar is designed to “base out” the Ringlock scaffolding system sitting on top of the screw jack creating a lower node point.

   Production work shop and Packing photos

Future of the Ringlock scaffolding systems :

     1.Ring lock scaffoldingis a multi-purpose modular scaffold system,  application in all forms of working platform and support structures in the building and construction industries, ship buliding, offshore construction and industrial maintennace, bridge tunnel, and other projects.

     2.Ringlock scaffoldingsystem inlculdes: standard, ledger, diagonal brace, steel boards, steel ladder, jack base, base collar, etc.

     3. Ringlock scaffolding is the latest wedge lock system which is easy assembly and time saving, just need to insert the ledger blade into standard plate, it only need a hammer to connect and seprate, cost you 5 seconds to finish the work, thus saves you a lot of time and effort.

     4. Ringlock scaffolding has high bearing capactity, as steel pipe material is Q235, thickness can be 2.75mm to 3.25mm, diameter 48.3mm. According to SGS test report and EN12810 certified, the whole Ringlock scaffolding with 3.25mm of thickness can load 32tons, 7tons for every standard.

     5. Ringlock scaffolding can be surface treatment red oil painting or Hot dip galvanized to further resist rust, cracking and corrosion, has no pollution or harm to the evironment and people, which make sure of its low damage and longer life span.

     6. Ringlock scaffoldingstandard and ledger can be packed by steel wiress in steel pallet that occupy less space, it is easy to shipping and special suitable for container packing.





About us



We specialized in the filed of the hardware and scaffolding systems for10 years time and we dealing with many kinds of the Scaffolding .like Ringlock.Cuplock.Kwikstage scaffolding .frame systems. Shoring propsystems. hardware like handtools, Auto Tools. Building tools, such as the ratchet wrench.Pickaxe, Firmer chisel,shovel, pickaxe,various hammers,Triangle bricklayer,Scraper and so on. We want to emphasize that our goods get the reputation in the market due to the competitive price with the high quality. please do not hesitate to contact us meanwhile we will offer you the best with the quality you satisfied.
