series kneader for semipowder

Specifications

series kneader for semipowder Z arm blade,made by stainless steel with electric heating jacket .



: We are yuanda chemical machinery factory and specialised in producing chemcial macinery such as the Unsaturated polyester resin equipment SMC SHEET MACHINE kneader machine ,grinding machine,experiencial machine,hot melt glue machines and other chemcial machines and we have dealed with many years in the world market  and enjoy a good reputations in the Eurpopean countries and north America markets and our producing technologys have invited many foreign advanced technologys especially in UK



This is the details of the sigma mixer machine:



this series kneader can knead all kinds of CMC with different viscous and it always used in checmials,plastics,rubbers,ink,carbon element,medicines,food and other areas,and the blade is made by the stainless steel,and it can ensure the purity and the quality of the products.this machine adopts "Z"type dubble mixing,and can help the material react quikly and uniform,

I have make a data excel ,and you can chose it :

Modle

Capacity

Stirring speed

Main motor power

Steam heating pressure

Electric heating

jacket

Dimension(mm)

Weight

NH-500L

500L

37,21(rpm)

15,/18.5Kw

0.3Mpa

16.2Kw

With colling jacket

3000*1000*1500

3000kg

NH-300

300L

37,21(rpm)

7.5, /11KW

0.3Mpa

6Kw

With colling jacket

1800*800*1400

1600kg

NH-100

100L

35,22(rpm)

4/ 5.5

0.3Mpaa

4Kw

With colling jacket

1645*775*1540

1250kg

NH-40

40L

45,23(rpm)

2.2

0.3Mpa

4Kw

With colling jacket

1170*1100*480

560kg

NH-1000

1000L

35,25(rpm)

20/30/37/45

0.3Mpa

25Kw

With colling jacket

3450*1300*1600

4500kg

NH-1500

1500L

30,16(rpm)

22/30/37

0.3Mpa

32.4Kw

With colling jacket

3600*1420*14800

5800kg

2000L

2000L

45,30(rpm)

45Kw

0.3Mpa

Use steam heating

With colling jacket

3900*1600*2100

6500kg

NH-5

5L

33,23(rpm)

0.75Kw

03Mpa

1Kw

With colling jacket

650*400*705

300kg



If you need this kind of the machine you can contact me ,and i will give you the suitable price for you

Thanks for your kindly inquiry



Prince Lee



Mobile: 0086 13455283042
