Hight quality vinyl printer cutting plotter machine

FOB Price

USD $4,500 - $5,500 / Set

1 Set(Min.Order)

Supply Ability 1000 Set / Sets per Month
Port Guangzhou
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	DBX-01 cutting machine	Model Number	CE5000-60
Voltage	100-120 VAC,220- 240 VAC,50/60 Hz, 100-120 VAC,220-240 VAC,50/60hz	Cache Capacity	2MB, 2MB
Paper Feed Width	60cm/120cm	Cutter Pressure	20 ~ 450 gf ( Points 38 level )
Cutting Width	60cm/120cm	Cutting Speed	1000 mm/s (39.4 ips)(45°direction)
Driver	Digital Servo Motor	Cutting Length	20cm
Repeat Cutting	cutting	Size	1487mm656mm1188mm

Product Description

Hight quality vinyl printer cutting plotter machine

product description

Item	CE5000-60
CPU	32-bit CPU
Construction	Microgrit Rollers, Moving Media
Driver systerm	Digital Servo Motor
Max cutting size	603 mm50 m (23.7"164")
Mechanical Resolution range	584 mm5 m (23"16.4")
Min Media width	50 mm (2")
Max Media width	712 mm (28")
Max media thickness	0.25 mm (10 mil)
Max cutting speed	600 mm/s (24 ips)(In all directions )
Adjustable cutter pressure	20-300 gf ( Points 31 level )
Minimum character matrix	Max height about 5 mm (0.2")
Mechanical Resolution range	0.005 mm (0.0002")
Programmable resolution	GP-GLTM:0.1/0.05/0.025/0.01 mm
	HP-GL:0.025 mm (0.001")
repeatability precision*1	0.1 mm/2 m (0.0039"/80") or better
Can loading pen number	1 pcs
Compatible cutter type	Graphtec Supersteel blades, 0.9MM and 1.5mm diameter
Compatible pen type	Graphtec water-based fibe-tip pen
Compatible Media	Vinyl film, Fluorescent, decal , light reflective(except high-luminosity),paint masking, banner, thermal transfer vinyl, flex, flock, ,pu,pvc image transfer media, vinyl print media, etc.
interface	Serial RS-232C/USB2.0 high speed ,IEEE-1284 Parallel (automatic identification)
Deta Buffer	2 MB
Comand modes	GP-GLTM/HP-GL(selectable in Command menu)
the default number of cutting parameters	8 group, users can set any gronp.
display panel	16 character* LCD screen
power supply input	100-120 VAC,220-240 VAC,50/60 Hz
power consumption	Max 70 VA
	10-35 ℃ (50-95 oF),35-75 % RH (not-condensing)
Recommended Resolution Environment	16-32 ℃ (60-90 oF),35-70 % RH (not-condensing)
Dimensions W/Stand ( WDH)	851 mm285 mm223 mm (33.5"11.2"8.7")
Equipment Weight W/stand	11.2 kg (24.7 lb.)
Accessories Including	power line	1pc
	Quick Start Manual	1pc
	Safe use manual	1pc
	User manual disc	1pc
	CB09UA cutter	1pc
	Cutting Master software	1pc
	SATA	1pc
	PHP32-CB09N Blade Holder	1pc
	Windows Drivers	1pc
	CE5000-60 Cutter Holder	0pc

We Provide the detail assembling Video for new customer step by step

Using heat transfer machine is a cost-effective,environmentally friendly and durable way to transfer images on textile products

Packaging & Shipping

1. Neutral package/carton package, as your request

2. If you have your own forwarder in China, we can offer Free Delivery for you in Guangzhou City!

3.Our products export all countries.We can according to your request by airmail.

We are the manufacturer of sublimation transfer paper,and mainly produce

sublimation transfer paper and mainly produce,100gsm high speed sublimation transfer paper, 100gsm full sticky/tacky sublimation transfer paper, dark and light t-shirt transfer paper,dye sublimation lik,also sublimation/pigment. And sublimation printer, heat press machine, the printer head, hydraulic pressure double working heat pressure machine, 3D vacuum heat press machine.

Why partner with Elephant ?

1.Ink manufacturer for 10 years ,ink factory of PRINT-RITE ,reliable quality

2.Fast, convenient and professional service contracts

3.We take care of all our new and regular customers, providing satisfactory cooperation.

4.We are flexible and open to suggestions and needs of our customers.

So DON`T hesitate anymore......

Hurry up to contact us get our competitive price!
